6.1. Memory Specific Adaptor

To perform reads and writes to external memory, you must use AXI initiators on the memory-specific adaptor's AXI memory mapped (AXI-MM) interface.

The following waveforms illustrate a write operation.

Figure 20. Write to EMIF through AXI-MM MSA Interface
