B.2. Safety Cautions

Thermal and Mechanical Injury

Certain components such as heat sinks, power regulators, and processors may be hot, heatsink fans are not guarded, and power supply fan may be accessible through guard. Care should be taken to avoid contact with these components.

Cooling Requirements

Maintain a minimum clearance area of 5 centimeters (2 inches) around the side, front, and back of the development product for cooling purposes; do not block power supply ventilation holes and fan.

Electro Magnetic Interference

This equipment has not been tested for compliance with emission limits of FCC and similar international regulations. Use of this equipment in a residential location is prohibited. This equipment generates, uses and can radiate radio frequency energy, which may result in harmful interference to radio communications. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment on and off, take measures to eliminate the interference.

Telecommunications Port Restrictions

The wireline telecommunication ports (modem, xDSL, T1/E1) on this product must not be connected to the Public Switched Telecommunication Network (PSTN) as it might result in disruption of the network. No formal telecommunication certification to FCC, R&TTE Directive, or other national requirements has been obtained.

Electrostatic Discharge Warning

A properly grounded ESD wrist strap must be worn during operation/installation of the boards, connection of cables, or during installation or removal of daughter cards. Failure to do so can damage components within the system.

Please return this product to Intel for proper disposition. If it is not returned, refer to the local environmental regulations for proper recycling; do not dispose this product in any unsorted municipal waste.
