B. Safety and Regulatory Information

ENGINEERING EVALUATION KIT - THIS DEVICE IS INTENDED FOR EVALUATION ONLY! NOT FCC APPROVED FOR RESALE

This product has not been tested or approved by any agency or approval body for Electrical Safety, Electromagnetic Compatibility, Wired, or Wireless Telecommunications at the time of distribution.

Sales are limited to product developers, software developers, and system integrators; FCC NOTICE: This development kit is designed to allow:
  • Product developers to evaluate electronic components, circuitry, or software associated with the kit to determine whether to incorporate such items in a finished product.
  • Software developers to write software applications for use with the end product. This kit is not a finished product and when assembled, may not be resold or otherwise marketed unless all required.

FCC equipment authorizations are first obtained. Operation is subject to the condition that this product does not cause harmful interference to licensed radio stations and that this product does accept harmful interference. Unless the assembled kit is designed to operate under part 15, part 18, or part 95 of this chapter, the operator of the kit must operate under the authority of an FCC license holder or must secure an experimental authorization under FCC Part 5 of CFR Title 47.

Safety Certifications that may be required for installation and operation in your region have not been obtained.


Section Content
Safety Warnings
Safety Cautions
