Critical Link is an embedded systems engineering firm with extensive experience developing electronics products for industrial, medical, scientific, and defense applications. Our engineering staff spans the necessary disciplines to ensure technical success, while accelerating time to market. Critical Link's depth of experience in image sensor technology, SoC & FPGA design, vision protocols, sensor integration, and signal processing expertise uniquely position us as a premier development partner and solutions provider.
Offerings
Offering
Critical Link's MitySOM-5CSx System on Module combines the Intel® Cyclone® V System-on-Chip (SoC), memory subsystems, and onboard power supplies. The SOM is production-ready, meaning development teams can rely on performance, availability, and support for industrial-length lifespans of 10+ years. The MitySOM-5CSx is available in a wide array of configurations. These include various speed grades, memory options, and operating temperature specifications (including commercial and industrial temperature ranges).
Offering
The MitySOM-C10L/G Development Kit supports Critical Link’s Cyclone® 10 FPGA-based modules. Each kit includes a compatible MitySOM-C10L or MitySOM-C10G module (see purchase table below for compatible modules) and a base board that features on-board debug UART to USB converter and 10/100/1000 Gb Ethernet communication interfaces, FMC HPC connector that is compatible with a wide range of existing add-on cards, and two 60-pin dual row connectors that provide additional IO expansion options. All powered from a single 12VDC input (adapter included) with onboard +3.3V/+5V/2.5V/1.8V power supplies. MitySOM-C10L development kits also include access to memory controller IP and reference designs from Synaptic Labs LLC.
Offering
The MitySOM-A10S is an Intel® Arria® 10 SoC SOM (system on module) for a wide range of industrial embedded applications. In addition to the A10 processor, the module includes on-board power supplies, two DDR4 RAM memory subsystems, micro SD card, a USB 2.0 on the go (OTG) port, and a temperature sensor. The MitySOM-A10S SOM provides a complete and flexible CPU infrastructure for highly integrated embedded systems. The MitySOM-A10S is available with a 270KLE Intel® Arria® 10 SX. Options for 160KLE and 480KLE devices are also available. This MPU can run a rich set of real-time operating systems containing software APIs expected by modern system designers. The architecture supports several operating systems, including Linux.
Offering
The MitySOM-A10S Development Kit supports Critical Link’s Intel® Arria® 10 SoC based modules. Each kit includes a compatible MitySOM-A10S module and a base board that together feature an array of interfaces and expansion headers such as FMC, USB 2.0 OTG, USB Console, PCI-e x4 Expansion Header, Gigabit Ethernet, and eMMC/SD Card.
Offering
Critical Link is an embedded systems engineering firm with extensive experience developing electronic products for industrial, medical, scientific,and defense applications. Our engineering staff spans the necessary disciplines to ensure technical success, while accelerating your time to market. Many customers benefit from our ground-up design services, but Critical Link also offers customization of our off-the-shelf System-on-Modules (SOMs) and imaging platforms. This approach ensures product development success against even the most aggressive budgets, schedules, and technical resource constraints. Our range of experience and key technology partnerships uniquely position us for challenges in the areas of SoC-based system design Analog signal processing Digital signal processing Sensor integration (imaging sensors, photodetectors, vibration & temp sensors) Custom imaging/image processing Communications systems Motor control (Stepper, BLDC, Servo) Data acquisition Our SOM and Imaging Platforms are customizable for your application Sensor integration Hardware modifications FPGA development Signal processing algorithms Software optimization Interfaces With a versatile, seasoned engineering staff, our organization has broad experience in applications for Industrial Equipment & Automation Scientific & Medical Imaging Environmental Monitoring Alternative Energy Communications Systems Mesh Networking Broadcast Audio Equipment Inspection Equipment Test & Measurement Defense and Security Transportation Telecommunications Equipment Navigation Systems Radar Systems Full lifecycle capabilities Systems engineering Hardware design Firmware Software Mechanical engineering Prototyping Testing Transition to production Manufacturing Interested in knowing more? Visit our website at http://www.criticallink.com or contact us at info@criticallink.com. We'll be pleased to review your needs or questions, and offer feedback.
Offering
The MitySOM-5CSx Development Kit supports Critical Link’s Intel® Cyclone® V SoC based modules. Each kit includes a compatible MitySOM-5CSx module (see Purchase table below for compatible modules) and a base board that features an array of interfaces and expansion headers such as USB, Debug RS232 to USB Console, Full HSMC Expansion Connector, Partial HSMC Expansion Connector, PCI-e x4 Expansion Header, MMC/SD Card, Gigabit Ethernet and Dual CAN Bus interfaces.
Offering
The MitySOM-5CSx with Dual Side Connectors (MitySOM-5CSx-DSC) is a highly configurable, small form-factor System-on-Module (SOM) featuring an Intel® Cyclone® V System-on-Chip (SoC). In addition to the processor, the module includes on-board power supplies, NOR FLASH, a DDR3 RAM memory subsystem, a real time clock (RTC), micro SD card, a USB 2.0 on the go (OTG) port, and a temperature sensor. The MitySOM-5CSx-DSC provides a complete and flexible CPU infrastructure for highly integrated embedded systems. The MitySOM-5CSx-DSC is available with a 110KLE Intel® Cyclone® V SX. This MPU can run a rich set of real-time operating systems containing software applications programming interfaces (APIs) expected by modern system designers. The architecture supports several operating systems, including Linux, Micrium uC/OS, Android and QNX.
Offering
The MitySOM-A10S with Dual Side Connectors (MitySOM-A10S-DSC) is an Intel® Arria® 10 SoC board-level solution for machine vision and scientific imaging applications, and other stack-through configurations. In addition to the A10 processor, the module includes on-board power supplies, two DDR4 RAM memory subsystems, micro SD card, a USB 2.0 on the go (OTG) port, and a temperature sensor. The MitySOM-A10S-DSC provides a complete and flexible CPU infrastructure for highly integrated embedded systems. The MitySOM-A10S-DSC is available with a 270KLE Intel® Arria® 10 SX. Options up to 480KLE devices are available. This MPU can run a rich set of real-time operating systems containing software APIs expected by modern system designers. The architecture supports several operating systems, including Linux.
Offering
The MitySOM-C10G series of highly configurable, small form-factor System-on-Modules features an Intel® / Altera®/Cyclone®10 GX field programmable gate array (FPGA) and include on-board power supplies, NOR FLASH and DDR3L memory subsystems. The MitySOM-C10G delivers a low power, flexible, low cost FPGA solution for rapid development and deployment of new designs. Using a NIOS II Softcore processor, the MitySOM-C10G provides a complete and flexible CPU infrastructure for a low cost integrated embedded system. The MitySOM-C10G has been designed to support several upgrade options. These include various FPGA densities, speed grades, and operating temperature specifications (including commercial and industrial temperature ranges).
Offering
The MitySOM-A5E is a system on module featuring the Intel Agilex® 5E SoC with up to 656KLE FPGA fabric, optional transceivers, on-board power supplies, and LPDDR4 RAM memory subsystems. The SOM measures a compact 2" x 2.8". Critical Link's MitySOM-A5E is a production-ready solution designed for long term availability to support a broad range of applications.
Offering
The MitySBC-A5E is a single board computer featuring an Intel Agilex® 5E SoC (System on a Chip) and includes up to 656KLE FPGA fabric, on-board power supplies, and memory subsystems. The Intel Agilex® 5 delivers 2.5x the performance at 50% less power consumption versus the Cyclone® V SoC. Critical Link's MitySBC-A5E is a production-ready solution designed for long term availability to support a broad range of applications.
Offering
The MitySOM-5CSx Development Kit supports Critical Link’s Intel® Cyclone® V SoC based modules. Each kit includes a compatible MitySOM-5CSx module (25KLE to 110KLE options available, commercial & industrial temp) and a base board that features an array of interfaces and expansion headers such as USB, Debug RS232 to USB Console, Full HSMC Expansion Connector, Partial HSMC Expansion Connector, PCI-e x4 Expansion Header, MMC/SD Card, Gigabit Ethernet and Dual CAN Bus interfaces.
Offering
Critical Link’s depth of experience in image sensor technology, SoC & FPGA design, vision protocols, and signal processing expertise uniquely position us as a premier development partner in imaging system design. We work with OEMs in industrial, scientific, medical, & defense markets to design and manufacture custom imaging platforms. Sensor Brand Experience SONY AMS / CMOSIS e2V HAMAMATSU Fairchild Imaging OmniVision Sensors Unlimited OnSemi Our engineering team has designed imaging platforms around a wide array of image sensor technology, including CMOS/sCMOS CCD EMCCD Linescan InGaAs Infrared SWIR Imaging Protocol Experience USB3 Vision GigE Vision CameraLink USB 2.0 HDMI DisplayPort Digital I/O GenICam Ethernet Full Lifecycle Capabilities Systems engineering Hardware design Firmware Software Mechanical engineering Prototyping Testing Transition to production Manufacturing Interested in knowing more? Visit our website at http://www.criticallink.com, or contact us at info@criticallink.com. We'll be pleased to review your needs or questions, and offer feedback.
