Denverton NS
Intel Atom® C3000 processor series, formerly Denverton, is Intel’s third generation system-on-a-chip (SoC)-based CPU manufactured on Intel’s optimized 14nm process technology. The platform extends industry-leading performance per watt, low thermal design power (TDP), and unprecedented levels of configurable high-speed I/O for accelerated innovation across networking, storage, Internet of Things (IoT), and scalable solutions. It also offers extensive software integration functionality, including Intel® QuickAssist Technology (Intel® QAT) to accelerate and compress cryptographic workloads.
Key features on Denverton NS
- Performance for high-density, low-power designs Performance improvements over previous generations with an integrated/high-density design and low TDP.
- Multi-core scalability Multiple product configuration options from 2–16 processing cores to scale one design across many use cases.
- High-speed I/O configurability Faster transmission of large data files with 10Gb Ethernet and configurable I/O lanes using PCIe gen 3*, SATA and USB 3.0.
- Server-grade capabilities Integration with Intel® QAT for compression and cryptography acceleration, and new reliability, availability, and serviceability (RAS) functionality.
- Long life and extended temperature for demanding IoT designs Select processors offer 15 year availability and 10 year product reliability with extended temperature ranges from -40°C up to +85°C.
- Innovation engine Enables next-generation systems to customize solution firmware to drive greater operational efficiency, security, and predictive maintenance.
- Intel® Virtualization Technology (Intel® VT) Intel® VT allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
What you can do with Denverton NS
Industrial & manufacturing
Create new and innovative industrial designs that can deliver ROI, withstand the test of time, and operate as expected in extreme use conditions
Smart cities
Make quicker and more intelligent machine and factory floor decisions with faster access to critical data being generated by bandwidth-intensive applications
Robotics
Take advantage of greater scalability, flexibility, and manageability features in one platform for a broad spectrum of robotic designs and applications
Energy
Add server-grade safeguards to energy applications by taking advantage of greater integration of accelerated security and networking functionalities.
Platform components for Denverton NS
Processor |
Cores |
Base non-AVX |
TDP (W) |
IoT |
Ordering code |
|---|---|---|---|---|---|
16 |
2.1 |
32 |
- |
HW8076503528301 |
|
16 |
1.7 |
24 |
- |
HW8076502638901 |
|
12 |
2.1 |
25 |
- |
HW8076502639201 |
|
12 |
1.9 |
21 |
- |
HW8076502639101 |
|
8 |
2.2 |
21 |
- |
HW8076502639002 |
|
16 |
2 |
31 |
- |
HW8076502444202 |
|
12 |
2 |
25 |
- |
HW8076502639501 |
|
8 |
2.2 |
25 |
- |
HW8076502639402 |
|
4 |
2.2 |
16 |
- |
HW8076502639302 |
|
4 |
2.1 |
15 |
- |
HW8076502444301 |
|
2 |
1.5 |
8.5 |
- |
HW8076502639602 |
|
12 |
2 |
24 |
Y |
HW8076502639702 |
|
8 |
1.7 |
17 |
Y |
HW8076502640002 |
|
4 |
1.6 |
11.5 |
Y |
HW8076502639902 |
|
2 |
1.6 |
9.5 |
Y |
HW8076502639802 |
| OS type | Operating system1 (Targeted for Support) | Support2 | Distribution | BIOS |
|---|---|---|---|---|
| Linux | Red Hat* Enterprise Linux 7.3, 7.4 | Red Hat |
American Megatrends Inc |
|
| SUSE* Linux Enterprise Server 12 SP3 | SUSE, Open Source | SUSE | ||
| Ubuntu* 16.04. 16.10, 17.04 LTS | Canonical, Open Source | Canonical | ||
| Yocto* Linux 2.1 | Intel, Open Source | Yocto Project* | ||
| CentOS* 7.3 | Open Source Community | |||
| Windows* | Microsoft Windows* Server 2016 (including Nano Server), Server 2012 R2 | Intel, Microsoft | Microsoft | |
| VMM | Linux KVM (RHEL 7.3, 7.4) | Open Source | ||
| Microsoft Windows* Hyper-V | Microsoft | |||
| Xen* 4.9 | Linux* Foundation, Open Source | |||
Product and Performance Information
This is the OS list that is tested internally and does NOT reflect the OS vendor support for these exact release versions. Please contact respective OS vendor(s) for the release version numbers and support. Several software patches will be upstreamed and will be picked up over time. These will be required to enhance platform support.
Intel only provides support for our tools, patches and utilities on the OS. Actual OS support should come from the OS Vendor.
