Since 2000, reflex ces has designed and manufactured high-speed boards and rugged systems solutions based on high density FPGAs that significantly reduce its customers’ technology risks. The company provides custom embedded and complex systems, and specializes in Modified-Off-The-Shelf (MOTS) solutions for VPX, OpenVPX, Compact PCI, VME rugged systems, embedded systems, industrial systems but also a complete portfolio of COTS of high-speed boards, FPGA boards, PCIe boards, portable and rackable computer and recorder. reflex ces also proposes Instant Development Kits for prototyping or production usages with FMC boards. Its expertise spans from chip-level and software-level designs up to complete system-level designs, manufacturing, and production of small and medium series of turn-key systems targeting customers in the Defense, Bioscience, Instrumentation, Fintech and networking sectors.
Offerings
Offering
The PCIe carrier board of the Achilles Intel® Arria® 10 SoC SoM provides access to all the features of the systeme on module based on Arria® 10 SoC (Ethernet, OTG USB, Transceivers, UART) and adds further functions, including SFP+ connectors, PCIe x8 Gen3, USB3.0,Wifi interface. This PCIe carrier board is an optional extra product for clients looking for a PCIe format card. We also can propose the design of a custom carrier board.
Offering
The PCIe Carrier Board of the COMXpressSX Stratix® 10 is an evaluation carrier board with standard and high speed connectivity. It's designed to be use quickly in server platform with PCIe x16lanes.The target applications includes IP prototyping, military and aerospace, machine and intelligent vision, test & measurement, medical, industrial, HPC and data center, video broadcast, video application, test & measurement, medical.
Offering
The AV153 is a cutting-edge solution from our range of Ultra Wideband Radar, ECM, and SIGINT systems, built on the robust VITA47 ECC3 VPX standard. The main features of the board are: ⸱ Direct-RF SOC altera® Agilex® 9 AGRW027 ⸱ 8 channels 64 Gsps 10-bit ADC ⸱ 8 channels 64 Gsps 10-bit DAC ⸱ Analog bandwidth up to 20 GHz ⸱ Two Ultra Low jitter clock synthesizers ⸱ External or internal sampling clock reference ⸱ 2x 64-bit 8GBytes DDR4 2400 SDRAM (Fabric) ⸱ 1x 32-bit 4GBytes DDR4 2666 SDRAM (HPS) ⸱ Conduction Cooled ⸱ SOSA-aligned. Designed in full compliance with the SOSA standard, the AV153 ensures compatibility with various communication protocols, such as PCIe, Gigabit Ethernet, and numerous user-defined I/Os. This board is perfectly suited for applications in Phased-Array Radar Transmitter/Receiver systems, Electronic Warfare (ESM/ECM), and Broadband Communication, targeting a wide range of demanding markets.
Offering
The Ares SoM is an Intel Agilex® SoC F-Series system-on-module, based on the Intel Agilex® 7 FPGA SoC F-Series. The main advantage of theAres Agilex™ 7 SoC F-Series FPGA is its flexibility and high-performance capabilities, enabling designers to efficiently implement complex algorithms and integrate multiple functions onto a single chip, resulting in reduced power consumption, and improved system performance and technology. The system-on-module (module SoM) is delivered with an active heatsink with heat spreader and fan. Target markets of this Ares Agilex™ SoC F-Series module include bioscience, high precision measurement, radar systems, electronic warfare, and etc. The Ares Agilex™ SoC F-Series module will be fully compatible with its the carrier board. Ordering information: RXCAGF012PR24-SOM00I.
Offering
The Achilles Arria® 10 SoC System-on-Module is based on the Intel® Arria® 10 SoC FPGA, and is available in three different version, The main features are :Intel® Arria® 10 SX 270 or 660 KLE ; PCIe Gen3 x8228 SE IOs total (113 LVDS)24 transceivers up to @10Gbps2x DR4 banks up to 2400MT/industrial TempTarget markets: life science instrumentation, embedded industrial, printing machines, radar systems The Achilles Arria® 10 SoC SoM is shipped alone. This system-on-module is also available in a development kit with a starter board. Ordering information:Board "Lite" version // RXCA10S027PF34-SOM00LBoard "Turbo" version // RXCA10S066PF34-SOM00TBoard "Indus" version // RXCA10S066PF34-SOM00I
Offering
The XpressGXA10-LP1151B is a low-profile PCIe network processing FPGA board, featuring 40G Ethernet. The main features are: Low-profile PCIe board using Intel® Arria® 10 GX 1150 KLE Single slot passive cooling for servers Designed for fog computing and ultra low latency applications PCIe Gen3 x8 interface 8 GB on board DDR4 (x 72bit) QSFP+ cage 10/40 GbE ports Board Management Controller (BMC) 10 transceiver expansion port 10 GPIO expansion port The Target applications are as wide as Fog Computing, Finance, Acceleration, Networking and Security.
Offering
The board is based on an Intel® Stratix® 10 GX FPGA, L-Tile and H-Tile compatible. The main features of the board are: Full height PCIe board using Intel® Stratix® 10 GX or SX 2800 KLE Designed for Acceleration and Low Latency Applications PCIe Gen3 x16 3 independent banks on board DDR4 2 independent banks on board QDR2+Xtrem QSFP28 optical cages, 10/25/40/100 GbE ports 200G board to board capability (FireFly) Board Management Controller (BMC) IO and transceiver extension connectors The target markets are as wide as Data center and Cloud Computing, Finance, High performance Computing, Military & Defense, Broadcast and video
Offering
The board is based on an Intel® Stratix® 10 GX FPGA, H-Tile. The main features of the board are: Full height PCIe board using Intel® Stratix® 10 GX 2800 KLE FPGA Designed for Acceleration and Low Latency Applications PCIe Gen3 x16 4 independent memory banks compatible DDR4 and QDR2+ 4 QSFP-DD optical cages, 10/25/40/100 GbE Board Management Controller (BMC) 3 Ultraport Slim SAS connectors for storage solution The target markets are as wide as Data Center and Cloud Computing, Finance, High Performance Computing, Military & Defense, Broadcast and Video
Offering
The Alaric board is designed for high performance serial transceiver applications using series 10 SoC FPGAs Intel® Arria® 10 SoC 660 KLEs in F34 package compliant 660 KLEs. The main features of the board are: Hardware, software design tools, IP, and pre-verified reference designs. PCIe device with 4 lanes at 8 Gb/s link rate (Gen3) and PCIe root with 4 lanes at 8 Gb/s link rate (Gen3) Advanced memory interface with DDR3 on board Memory up to 4GB Develop networking applications with 10/100/1000 Mbps Ethernet (GMII, RGMII and SGMII) Implement Video display applications with Display output port (up to 5.4Gbit/s) The board respect the VITA57.1 standard, you can plug FPGA Mezzanine Card (FMC) on the front end The FMC interface provides High Pin Count (HPC) fully populated, compliant +1.8V only ( +vadj): 160 LVCMOS (1.8V) usable as 80 LVDS (1.8V, 2.5V) 4 dedicated LDVS clocks that respect the VITA57.1 pinout assignment usable as LVDS signals or 8 LVCMOS 10 XCVR (up to: 14.2 Gb/s)* * Production Device with transceiver speed grade 3 can reach 14.2 Gb/s chip to chip links, The VITA 57.1 standard allows interfaces up to 10 Gb/s The target markets are as wide as Video capture and processing, Industrial, Test & Measurement and Medical.
Offering
The Intel® Arria® 10 SoC SoM provides to developers the best Out-Of-The box experience combining the Best-In Class compact hardware platform and the most efficient intuitive software environment. Featuring an ARM dual-core Cortex-A9 MPCore and up to 660KLEs of advanced low-power FPGA logic elements, the Intel® Arria® 10 SoC combines the flexibility and ease of programming of a CPU with the configurability and parallel processing power of an FPGA. The main features are : Intel® Arria® 10 SX 270 or 660 KLE ; PCIe Gen3 x8 220 SE IOs total 24 transceivers @10Gbps 2x DR4 banks up to 2400MT/s Industrial Temp Ultra compact form factor at only 86x95 mm (3.4x3.8 inches) is ideal for area constrained applications Careful board layout enables superior signal integrity, support for multi-Gigabit serial protocols, including PCIe Gen3 and 10G Ethernet Comprehensive reference designs available enable out-of-the-box experience, designs provided with source code Standard Linux Debian support, allows seamless porting of existing application software The target markets are as wide as Automotive, Video Broadcast, Machine and Intelligent Vision, Industrial, Military, Test & Measurement and Medical. Achilles Instant-DevKit is comprised of the Intel® Arria® 10 SoC SoM plus a Starter board for quick prototyping and application testing. REFLEX CES offers the possibility to buy the A10 SoC System-on-Module separately. We also offer a PCIe Carrier Board as an optional extra, or can propose the design of a custom Carrier Board.
Offering
The Sargon board is based on Intel® Stratix® 10 GX 2800 KLEs FPGA. The main features of the board are: PCIe Gen3 x16 Board Management Controller (BMC) for monitoring, NOR Flash and clock programming 2x banks DDR4 vertical RDIMM 1x bank DDR4 on board FMC+ interface and additional connectors 2x FireFly board-to-board connector 1x mini-SAS HD for storage The target markets include High Performance Computing and IP & ASIC Prototyping.
Offering
The XpressGXA10-LP1150T is a Low Profile Intel® Arria® 10 GX PCIe board which provides to customers an off-the-shelf Best-In Class hardware solution for HPC or Networking applications. The main features are: On board one DDR4 and four QDR2+ independent banks Two QSFP+ optical cage for multi networking solutions PCIe device with 8 lanes at 8 Gb/s link rate (Gen3) Fail safe configuration flash sector Configuration via protocol (CvP) JTAG connector Extension connector for inter board communication (16 transceiver lanes) The XpressGXA10-LP1150 high-end board allows all engineers to design complex applications using PCIe and 10 Gigabit Ethernet as their main communication interfaces. The XpressGXA10-LP1150 is a low-profile, highly-integrated PCI Express FPGA board with quad-10G or 40G Ethernet channels engineered for both prototyping and field deployment.
Offering
The board is based on Intel® PSG Stratix® 10 GX or SX FPGA, with a COM Express Basic form factor, type 7 standard. Main features are: Intel® Stratix® 10 SX Technology - 2800 KLE density Designed for High Performance Computing and Acceleration 32 PCI Express lanes IO and Transceiver extension connector on-board 56GB DDR4 + ECC Target markets include HPC & Analytics, Acceleration, Intelligent vision & Video processing
Offering
The board is based on an Intel Agilex® I-Series SoC.The main features of the board are: Intel Agilex® I-Series SoC FPGA ⸱ Quad Core ARM® Cortex® A53 ⸱ 2700 KLE ⸱ PCIe Gen5 x16, CXL™ EP compatible ⸱ 400GbE (8 x 53 Gbps)⸱ 3x DDR4 banks⸱ 4x HSI connectors (2x PCIe Gen5 x16 EP/RP, 1x CXL™ EP compatible). The target markets are as wide as Security SmartNIC, Memory expansion & storage, and Networking Switch.
