Portwell, a world-leading innovator in Industrial PC and embedded computing solutions, and an IoT Solutions Titanium Partner of the Intel Partner Alliance, develops a wide-range of cutting-edge platforms to meet versatile needs of mission-critical applications. We provide board-level solutions along with high quality and real-time industrial-level system integration service to deliver decent performance, reliability and scalability to our customers. We provide complete R&D and project management services to decrease customers' time to market, reduce project risk and cost. Portwell is also an ISO 9001, ISO 14001 and ISO 13485 certified company which deploy quality assurance through product design, verification and manufacturing cycle.
Offerings
Offering
Intel® 12th/13th Generation Core™ processor based on PICMG 1.3 SHB with DDR5 SDRAM,HDMI, DVI-D, DP, dual gigabit ethernet, audio and USB.
Offering
Intel® 12th/13th/14th Generation Core™ processor based on PICMG 1.3 SHB with DDR5 SDRAM,HDMI, DVI-D, DP, dual gigabit ethernet, audio and USB.
Offering
PNSR-5001 is a 1U rackmount network appliance powered by Intel® Xeon® D-2800/D-2700 Series Processors, featuring up to 22 cores, and designed with three OCP NIC 3.0 network adapters. More specifically, the PNSR-5001 supports three OCP NIC 3.0 expansion slots, with two slots supporting PCIe Gen4 x16 from CPU, and the other supporting PCIe Gen3 x8 from HSIO. All three OCP NIC 3.0 slots are compatible with OCP NIC 3.0 (SFF/TSFF) off-the-shelf network adaptors. Each OCP NIC 3.0 slot has an independent SMBus and USB 2.0. With Portwell’s proprietary PNC series of network adapters, PNSR-5001 can enable Ethernet Bypass function by application-centric request. Equipped with one of the most mainstream BMC chips, the AST2500 on-board, PNSR-5001 provides rich I/O elements, including a console port, two USB 3.2 Gen 1 ports, three USB 2.0 headers on-board, and an LCD display module with control buttons. The I/O interface also contains two LEDs for PSU power status and storage drive (HDD) status. Additionally, the PNSR-5001 supports two SATA 3.0 for 2.5” hard drives, one on-board M.2 M key, one M.2 B key for cellular modules, and one M.2 E key for WiFi module.
Offering
Portwell's PNSR-5000 is a 1U Rackmount network appliance powered by the Intel® Xeon® D-1800 and D-1700 processors, featuring up to 10 cores, PCIe Gen 4 and more high speed I/Os. The PNSR-5000 supports two channels DDR4 RDIMM/UDIMM (up to 2933MHz) and maximum memory capacity up to 256GB. With 16 PCI Express Gen 4 lanes, the PNSR-5000 can support 2 NIC modules, support multiple Ethernet module bays for flexible port configuration; such as 1/10/25/40 Gigabit fiber, Gigabit copper with BYPASS function or not. The OCP 3.0 and standard PCIe convertible slot design makes expansions more flexible and easier. PNSR-5000 also natively supports two 10/25GbE SFP+/SFP28 with up to 50 Gigabit throughput and six 2.5GbE copper on-board with BYPASS function. The strong I/O elements of PNSR-5000 include a console port, two USB 3.2 Gen 1 ports, a Graphic LCD module with keypad (4 keys), LEDs for power/ HDD/ Bypass/ SFP28 ports. In addition, the PNSR-5000 also supports two 2.5” SATA HDDs/SSDs, on-board one M.2 2280 for network storage application, one M.2 Key B 3052 for 4G/5G/LTE module, and one M.2 Key E 2230 for Wi-Fi module.
Offering
DIN-Rail Embedded SystemCompact, Fanless, Wide-Temp Design– Saves space, improves reliability, enables silent operation, and adapts to harsh industrial environments.Three Network Ports – 3GbE– Meets multi-network segment requirements of industrial control, provides bandwidth redundancy and overall traffic needs.Dual HD Display– Improves multitasking efficiency and workflows, suitable for diverse applications.Rich Wireless Expandability– Supports 5G and Wi-Fi 6 for high-speed and stable wireless connections to meet current and future device requirements.
Offering
Embedded Rugged Fanless System with 14th/13th/12th Generation Intel® Core™ i3/i5/i7/i9 based Mini-ITX Board
Offering
ANS-9142 series builds on Intel® Atom C3436L / C3338R processor with up to four CPU cores. ANS series is a compact system with up to 8x GbE ports and it is suitable for SDN (SD-WAN) applications with 5G and WiFi 6 deployment.FEATURES1. Intel® Atom C3436L(4C) / C3338R(2C) Processor 2. 8x GbE RJ45 1x RJ45 Console, 2x USB 3.03. 1x DDR4 1866 MT/s ECC and non-ECC SO-DIMM up to 32 GB4. 1x TPM 2.0 (on-board)5. 1x M.2 Key-E Slot (PCIe/ USB2.0), 1x M.2 Key-B Slot (PCIe/ USB3.0), 1x M.2 Key-M Slot (SATA)6. Design ready for 5G and WiFi 6 (802.11ax)7. Compact design 2 in 1U rackmount
Offering
Intel® new generation networking processor based on type 7 basic COM Express 3.0 module with DDR4 ECC/Non-ECC SDRAM on three SO-DIMM sockets, 20 PCIe lanes, 10GbE, NC-SI interface, SATA, and USB.
Offering
Intel® New Generation Networking Processor Based on Type 7 Basic COM Express 3.0 Module with DDR4 ECC/Non-ECC SDRAM on Three SO-DIMM Sockets, 20 PCIe Lanes, 10GbE, NC-SI Interface, SATA, and USB, new type 7 Specification with new server platform. Support DDR4-2133 ECC/Non-ECC SDRAM on Three SO-DIMM Sockets, up to 48GBFour 10GbE and One GbE Interfaces4x USB 3.0/2.0, 2x SATA III, 12x PCIe x1 Gen 2.0, 1x PCIe x8 Gen 3.0Wide-Temp (-40°C to +85°C), support on selected SKUs.
Offering
PCOM-B657VGL is a COM Express Type-VI Basic module powered by 11th Gen Intel® Core™, Intel® Xeon® W-11000E Series, and Intel® Celeron® processors (codenamed Tiger Lake-H). It offers support for 2x DDR4 ECC/Non-ECC SO-DIMMs, 1x PCIe Gen 4 x16, 8x PCIe Gen 3 x1, 4x USB 3.2 Gen2x1, 4x USB 2.0, 2.5 Gigabit TSN Ethernet, 4x SATA III, 3x DDI, eDP/LVDS, VGA, and discrete TPM 2.0
Offering
ANS-9A44F/42F series builds on Intel® C3758R / C3558R processor with up to eight CPU cores. This ANS series is a compact system with up to 2xSFP+, 2x GbE ports, 2x GbE PoE+ ports and 4x Combo ports, it is suitable for SDN (SD-WAN) application with 5G and WiFi 6 deployment.Features:Intel Atom® C3758(8C)/ C3558R(4C) Processor2x 10Gb SFP+, 2x GbE RJ45, 2x GbE RJ45 PoE+, 4x Combo Ports1x RJ45 Console, 2x USB 3.02 x DDR4 1866 MT/s ECC and non-ECC SO-DIMM up to 32GB1x TPM2.0(on-board)2x M.2 Key-E Slot(PCIe/ USB2.0), 2x M.2 Key-B Slot(PCIe/ USB3.0), 1x SATADOMDesign ready for 5G and WiFi 6 (802.11ax)Compact design 2 in 1U rackmount
Offering
APTNS-13181 is a 1U rackmount network appliance powered by Intel® Xeon® D-2700 Series Processors (formerly Ice Lake-D HCC), featuring up to 20 cores, and designed with three OCP NIC 3.0 network adapters. More specifically, the APTNS-13181 supports three OCP NIC 3.0 expansion slots, with two slots supporting PCIe Gen4 x16 from CPU, and the other supporting PCIe Gen3 x8 from HSIO. All three OCP NIC 3.0 slots are compatible with OCP NIC 3.0 (SFF/TSFF) off-the-shelf network adaptors. Each OCP NIC 3.0 slot has an independent SMBus and USB 2.0. With Portwell’s proprietary APTNC series of network adaptors, APTNS-13181 can enable Ethernet Bypass function by application-centric request. Equipped with one of the most mainstream BMC chips, the AST2500 on-board, APTNS-13181 provides rich I/O elements, including a console port, two USB 3.2 Gen 1 ports, three USB 2.0 headers on-board, and an LCD display module with control buttons. The I/O interface also contains two LEDs for PSU power status and storage drive (HDD) status. Additionally, the APTNS-13181 supports two SATA 3.0 for 2.5” hard drives, one on-board M.2 M key, one M.2 B key for cellular modules, and one M.2 E key for WiFi module.
Offering
Intel® Core™ i7/i5/i3/Celeron® (formerly "Tiger Lake"-UP3) Processor based on type 6 compact COM express 3.0 module with DDR4 SDRAM on dual SO-DIMM sockets, VGA, LVDS, display-port, GbE Port, SATA and USB 3.2 Gen111th Generation Intel® Core™ processors and Intel® Celeron® Processors (Codename: "Tiger Lake" UP3)Support DDR4-3200MT/s SDRAM on two SO-DIMM Sockets, up to 32GB two Display-Port, One VGA or One eDP/LVDS selection Output4x USB 3.2 Gen2, 8x USB 2.0, 2x SATA III, 1x PCIe Gen4 x4, 5 PCIe Lanes, and 1x GbE.
Offering
PCOM-B655VGL is Intel® Core™ ("Comet Lake-S") platform COM Express module. It is compatible with COMe 3.0 Type 6 carrier board. The desktop CPU on module offers customer higher computing power but lower cost comparing to mobile solutions. PCOM-B655VGL supports both ECC and Non-ECC DDR4 by different PCH SKUs(Q470E/W480E), which can be adapted to different applications. This module provides one PCIex16, eight PCIex1 (Option to one PCIex4), four USB 3.1 Gen2, and four SATA III. Intel® Core™ i7/i5/i3 14nm process(formerly "Comet Lake-S")Support 2x DDR4-2933 Non-ECC/ECC SO-DIMMs, up to 2x 16GBSupport USB2.0/3.1 Gen2, 4x SATAIII, 1x PCIe 3.0 x16, and 8x PCIe 3.0 x1Support LVDS, VGA, and 3x Display port/HDMI
Offering
Embedded System with Intel® 12th/13th Generation Core™ i3/i5/i7/i9 based proprietary PICMG 1.3 SHBwith DDR5 ECC SDRAM, HDMI, DP, Dual 5 Gigabit Ethernets, Audio and USB
Offering
IWOS series system, a multi-functional 5U/4U server grade with dual/quad MEC Arch modules system, powered by Intel® Xeon® E-2278GE 3.3GHz (TDP 80watt) processor; therefore, the IWOS series system is able to serve as a high quality performance in banking and education applications.
Offering
IWOS series system, a multi-functional 5U/4U server grade with dual/quad MEC Arch modules system, powered by Intel® Xeon® E-2278GE 3.3GHz (TDP 80watt) processor; therefore, the IWOS series system is able to serve as a high quality performance in banking and education applications.
Offering
Portwell Gen5 PCIe GPU tester. The board-level development consists of 3 parts: Motherboard: system host board to connect to BP and riser. Backplane: Expansion board to connect between MB and PCIE device. Risers cards: Consumable risers connect between MB/BP and BP/PCIE devices with counter feature and indications.
Offering
Intel Atom® x6000 series SoC based on Type 10 Mini COM-Express® module with LPDDR4 SDRAM
Offering
Intel Atom® x7000E Series SoC based NANO-ITX board with triple display, 2.5GbE LAN, USB 3.2 Gen2, M.2, SATA III support low-power Intel Atom® x7000E Series SoC and high-performance Intel® Core™ i3 N-Series SoC up to 16GB DDR4 3200MT/s non-ECC SO-DIMM support multiple displays via HDMI, DP, LVDS high-speed I/O with dual 2.5GbE and four USB 3.2 Gen2 multiple expansions with M.2 E key and B key support on-board TPM 2.0.
Offering
1U network appliance based on Intel® Xeon® D-1700 series SoC, featuring on-board 6x 2.5GbE RJ45 with Bypass and 2x 25GbE SFP28.
Offering
COM Express Type 7 Basic Module based on Intel® Xeon® D-1700 Processors with Three Channels and Four SO-DIMM slots
Offering
Embedded System with Intel® 12th/13th Generation Core™ i3/i5/i7/i9 based proprietary PICMG 1.3 SHBwith DDR5 ECC SDRAM, HDMI, DP, Dual 5 Gigabit Ethernets, Audio and USB.
Offering
COM Express Type6 Basic size module with Intel® 12th / 13th Gen H/P/U Processor DDR5 SO-DIMM, DDI, PCIe Gen 4, USB4, USB3.2 Gen2, 2.5 Gigabit TSN Ethernet, discrete TPM 2.0, eDP, SATA III-12th Gen Intel® Core™ ,Celeron® Series processors in Intel® 7 lithography-Up to 6x performance core + 8x efficient core, and up to 96x graphic execution units-2x DDR5-4800 non-ECC SO-DIMMs up to 2x 32GB, 1x PCIe Gen4 x8(H series), 2x Gen4 x4, and 7x PCIe Gen3 x1-4x USB3.2 Gen2, 8x USB2.0, 2x SATAIII, 3x DDI, VGA, eDP/LVDS, and optional 2x USB4
Offering
12th/13th Gen Intel® Core™ processor based SHB with DDR5 SDRAM, PCIe Gen 5, dual 5GbE, display, audio and USB.
Offering
COM-HPC® Client module Size B module with Intel® 12th Gen H/P/U Processor DDR5 SO-DIMM, DDI, PCIe Gen4, USB4, USB3.2 Gen2, 2.5 Gigabit TSN Ethernet, discrete TPM 2.0, eDP, SATA III.
Offering
The WEBS-21G0 builds on Intel® Whiskey Lake-U Core™ i SoC and takes advantages of Intel® Core™ mobile technologies that can support superior processing power and capability. Support two Gigabit Ethernet ports, two mini DP ports and M.2 2280 key M for storage. The WEBS-21G0 is an ideal platform which with high performance for fan-less applications in harsh environment, such as POS, kiosk, digital signage, transportation and automation.Features:-Supports Intel® Whiskey Lake-U series processor-1x DDR4 2400 non-ECC SO-DIMM, Up to 32GB-1x M.2 key M 2280 for storage-Supports Dual mini DP ports-1x Antenna hole for WiFi module-IP 40 Rating
Offering
LYNX-612E is a compact, fan-less and cable-less PC adopting a low power Intel® processor. With small form factor, DIN-rail mounting and wide voltage DC input, it can easily fit in industrial environment. Legacy RS-232 and RS-232/422/485 help communicate machine to machine; in the meantime, real-time data collected from manufacturing line will be sent to edge and cloud, which benefit factories to make optimal decisions.
Offering
LYNX-612G is a compact, fan-less and cable-less PC adopting by a low power Intel® processor. Targeting as an IoT gateway, the small system equips rich communication interfaces for data acquisition and server connection. Besides, reserved M.2 socket enables wireless function for remote controllability and manageability. Last but not least, it supports Universal IoT Connector Standard (UIC) to realize fast and easy cloud connectivity.
Offering
The WEBS-21A0 builds on Intel® Core™ processors and takes advantages of Intel® Core™ mobile technologies. that can support superior dual-core processing power and capability. Support two Gigabit Ethernet ports and one Half-Size Mini PCIe. The WEBS-21A0 is an ideal platform which with high performance for fan-less applications in harsh environment, such as POS, kiosk, digital signage, transportation and automation.
Offering
Intel® Core™ i7/i5/i3/Celeron® Whiskey Lake-U Processor Based on Type 6 Compact COM Express 3.0 Module with DDR4 SDRAM on Dual SO-DIMM Sockets, VGA, LVDS, Display-port, GbE Port, SATA and USB 3.18th Generation Intel® Core™ i7, i5, i3, Celeron Whiskey Lake ProcessorsSupport DDR4-2400MT/s SDRAM on Two SO-DIMM Sockets, up to 32GBOne Display-Port, One VGA, and One LVDS Output4x USB 3.1, 8x USB 2.0, 2x SATA III, 10x PCIe Lan, and 1x GbE
Offering
NANO-6063 is based on Intel® Atom™ Elkhart Lake family processor. This processor not only supports the range of industrial temperature standard which is from -40°C to 85°C but operates in low power consumption 12W with low-power consumption. Succeeding previous version, NANO-6062, the flexibility of systematic expansions is suitable for Medical, Panel PC and Kiosk. To support not only 2.5 GbE but Intel TSN/TCC, these functions are fit in Industrial Automation, and Digital Signage application.
Offering
Portwell NANO-6051 is designed with Intel® 8th Generation Core™ i5/i3 Processors based on NANO-ITX Board with mini DP, GbE LAN, USB 3.1, M.2 and Combo Audio jack
Offering
Portwell PCOM-B641VG is designed with Intel Atom® E3900 Series ultra low power processor with higher memory performance and advance graphic controller for Automation, Healthcare and Thin Client Systems.
Offering
Intel Atom® x6000 Series and Intel® Pentium® and Celeron® N and J Series Processors Based on Type 6 Compact COM Express 3.0 Module with DDR4 SDRAM on Dual SO-DIMM Sockets, VGA, LVDS, Display-port, GbE Port, SATA and USB 3.2 Gen2Codename: Elkhart LakeSupport DDR4-3200MT/s SDRAM on Two SO-DIMM Sockets, up to 32GBTwo Display-Port or One VGA selection Output and One eDP/LVDS Output2x USB 3.2 Gen2, 8x USB 2.0, 2x SATA III, 6 PCIe Lanes, and 1x GbE
Offering
Intel® Core™ i3/i5/i7/Pentium® Celeron®/Xeon® E Family processor based on PICMG 1.3 half size SHB with DDR4 SO-DIMM, mini DP,DVI-D, Dual Gigabit Ethernet, SATAIII, mSATA, Audio, USBROBO-6912VG2AR is based on Intel® C246 chipset to support both Intel® Xeon® and Core™ i3/i5/i7 processors. Built with flexible PCI express expansions, ROBO-6912VG2AR is suitable for Medical, Industrial automation, and Digital Signage application
Offering
LYNX-6110 is a compact, fan-less and cable-less PC adopting by a low power Intel® processor (formerly "Apollo Lake"). Developed to meet any heavy industrial standards, the rugged design makes sure its reliability as well as its stability to work in an extremely harsh environment. By providing basic I/O interfaces in a palm-sized box chassis, the system is suitable for industrial automation, smart factory, edge computing, and IIoT gateway applications.
Offering
Portwell Panel PC or PPC provides the highest computing power for our customers by adopting Intel® dual-core processor E3930 (formerly "Appollo Lake"). By offering an optional operating system, users can choose either Win 10, Android or Linux Ubuntu, which provides them with incredible flexibility. The Gigabit Ethernet is available and can be up to two ports. The bezel-free characteristic makes it also suitable to be placed at occasions that face end customers. The serial port control ability makes it still good for conventional industrial automation application.
Offering
Intel® Core™ (formerly "Kaby Lake-U") Processor based 4x4-inch mini PC Board with DDR4 SDRAM, Gigabit Ethernet, M.2(E&M key) socket, one SATA ports and 12V or 19V DC input
Offering
RUBY-D811 is based on Intel® Q370 chipset and Desktop processors including Intel® 8th Gen Core™ i3/i5/i7 SKU. This board supports DDR4, PCIe 3.0, and SATA III. Those features help you to build high performance and stable system.
Offering
WUX-7300U builds on Intel® Core™-i5 Processor(SoC) (formerly "Kaby Lake" -U) support dual channel DDR4 memory. Support one Gigabit Ethernet port and two M.2 socket(one Key E for Wireless,one Key M for SSD) and voltage of power input 12V or 19V.
Offering
The WEBS-35C3 builds on Intel® desktop Q170 chipset and takes advantages of Intel® Core™ i3/i5/i7 desktop processor technologies that can support dual DDR4 memory. Support two Gigabit Ethernet ports, different add-on card expansion options, one M.2 socket and one Mini-PCIe socket. The WEBS-35C3 is an ideal platform with rich I/O and high resolution for POS, kiosk, digital signage, and surveillance security monitoring applications.
Offering
Intel® Coffee Lake –S Refresh Processor with DDR4 ECC/Non-ECC SDRAM on Four SO-DIMM Sockets, PCI-Ex16, GbE, SATAIII, and USBSupport Intel® 9th and 8th Gen coffee Lake-S Refresh Processors up to 8 coresSupport DDR4-2400/2133 ECC/Non-ECC SDRAM on Four SO-DIMM Sockets, up to 64GBTwo GbE Interfaces8x USB 3.0, 2x USB3.1, 4x USB2.0(route to backplane), 5x SATA III(2ports route to backplane), 4x PCIe x1 Gen 3.0, 1x PCIe x16 Gen 3.0
Offering
ANS-2121/41/42 series builds on Intel® Apollo Lake processor E3900 family with up to four CPU cores. ANS series is a compact system with up to 10x GbE ports and PoE+ support, it is suitable for SDN (SD-WAN) application with 5G and IoT devices deployment.
Offering
ANS-8A62/64P series builds on Intel ® Denverton C3758/ C3558 processor with up to eight CPU cores. ANS Denverton series is a compact system with up to 2x SFP+, 13x GbE ports and PoE+ support, it is suitable for SDN (SD-WAN) application with 5G and IoT devices deployment.
Offering
MEDS-P1002 is 10.1" panel PC with Intel® Atom® x5-E3900 series processor mainly for medical equipment HMI(Human Machine Interface). With latest medical certification EN 60601-1 approved, MEDS-P1002 will be ideal medical equipment HMI for medical equipment manufacturer.
