3.3. Initialization and Reset Sequences

After device power-up and configuration, the D-PHY hard circuitry and soft IP is initialized.

An asynchronous system reset is required to initialize the PCS soft logic to a known good state. This system reset is internally gated with the PLL lock signal to guarantee that the logic comes out of reset only when the clocks are stable.

The initialization flow for both TX and RX modes is as follows:

  1. PLL achieves LOCK.
  2. INIT_DONE is asserted.
  3. PPI.Enable for the active lanes are asserted.
  4. Register D-PHY_CSR.Enable is set to ‘1’ (DEFAULT).

The D-PHY IP has a programmable register tINIT that allows the soft IP to implement the initialization sequence. The initialization states for both the D-PHY TX and RX mode are as follows:

Table 3.  Initialization States for TX and RX Modes
Mode State Exit State Exit Condition Line Levels
TX OFF/RESET TX_INIT Reset_n deasserted & PLL locked & PPI Enabled . Not LP-11
TX TX_INIT TX_READY A first stop state for a period longer than tINIT timeout as specified by the protocol. Init_done is asserted LP-11
TX TX_READY RESET Reset_n asserted or PLL unlocked or PPI disabled Active
RX OFF/RESET RX_INIT Reset_n deasserted & PLL locked & PPI Enabled Any
RX RX_INIT RX_READY Observe LP11 for tINIT LP-11
RX RX_READY RESET Reset_n asserted or PLL unlocked or PPI disabled Active

The following is a timing diagram for the initialization sequence for both D-PHY TX and D-PHY RX modes.

Figure 6. Initialization Sequence Timing Diagram

Each clock domain has both a synchronous and asynchronous reset. These signals are generated internally from the incoming system reset (gated with PLL lock) and D-PHY link’s PPI.Enable signal for data lane 0 properly synchronized to the destination clock domains.

The register interface uses the synchronous reset input port srst_axil_n. This reset domain is totally independent of the rest of the logic with no dependency on the system reset, PLL lock or init_done signals.
