Exceptional Performance, Incredible Productivity
Maximize your productivity, creativity and collaboration. With processor P-cores and E-cores, Intel® Core™ processors make advanced professional and creative applications smooth and easy, like VFX, 3D rendering, complex 3D CAD, AI development, and edge deployments. The Intel® W680 Chipset maximizes throughput and responsiveness, with support for 16 Processor PCIe Gen 5.0 lanes and increased DMI (from 3.0 to 4.0) connect throughput over previous generation to drive performance without slowdowns.
Easy to Secure & Manage
The Intel® W680 Chipset delivers hardened security and trusted reliability. Error Correcting Code (ECC) memory support minimizes errors and helps to deliver a stable engineering and design platform.2 When paired with the right Intel® Core processors, you can get support for the Intel vPro® platform, which gives businesses the tools to manage and secure workstations.3 Intel® Hardware Shield provides an evolving set of hardware-based technologies to reduce attack surface, all while reporting the current security configuration to the operating system. Plus, Modern Manageability with Intel® Active Management Technology (Intel ®AMT) and Intel® Endpoint Management Assistant (Intel® EMA) enable IT teams to remotely manage thousands of endpoints through the cloud inside or outside the corporate firewall.
Intel® W680 Chipset Features at a Glance
| Feature | Benefit |
|---|---|
Support for Intel® Core™ desktop processors (14th, 13th and 12th gen) |
Cross-generation compatibility. |
Intel® Volume Management Device |
User-friendly way to manage your storage devices that allows direct control and management of NVMe SSDs from the PCIe bus without additional hardware adaptors. |
Intel® Rapid Storage Technology for SATA storage |
With additional SSDs and hard drives added, helps provide quick access to digital photo, video, and data files, and data protection against a hard disk drive failure with RAID 0, 1, 5, and 10. |
Intel® Rapid Storage Technology for PCI Express* Storage |
Enables Intel® Rapid Storage Technology features such as RAID 0, 1, 5, and 10 with PCI Express-based NVMe SSDs connected via 12th Gen Intel® Core™ processors and the Intel® W680 chipset. |
Intel® Wi-Fi 6E Support |
Integrated Intel® Wi-Fi 6E AX211(Gig+) CNVi solution or Intel® Wi-Fi 6E AX210(Gig+) solution allowing you to connect up to Gigabit Wi-Fi speeds. |
Intel® Smart Sound Technology |
Integrated digital signal processor (DSP) for audio offload and audio/voice features. |
Intel® High Definition Audio |
Integrated audio support enables premium digital surround sound and delivers advanced features such as multiple audio streams and jack re-tasking. |
USB 3.2 Gen 2x2 |
Integrated USB 3.2 Gen 2x2 support provides data transfer performance with a design data rate of up to 20 Gb/s. |
USB 3.2 Gen 2x1 |
Integrated USB 3.2 Gen 2x1 support provides data transfer performance with a design data rate of up to 10 Gb/s. |
USB 3.2 Gen 1x1 |
Integrated USB 3.2 Gen 1x1 support provides data transfer performance with a design data rate of up to 5 Gb/s. |
USB 2.0 |
High-Speed USB 2.0 support with a design data rate of up to 480 Mb/s. |
USB Port Disable |
Enables individual USB ports to be enabled or disabled as needed. This feature helps provide added protection of data by preventing malicious removal or insertion of data through USB ports. |
Serial ATA (SATA) 6 Gb/s |
High-speed storage interface supporting up to 6 Gb/s transfer rates for optimal data access. |
SATA Port Disable |
Enables individual SATA ports to be enabled or disabled as needed. This feature helps provide added protection of data by preventing malicious removal or insertion of data through SATA ports. |
Intel® Platform Trust Technology |
Integrated Trusted Platform Module within Intel chipsets, supporting TPM 2.0 standard. |
PCIe Express 3.0 Interface |
Offers up to 8 GT/s for fast access to peripheral devices and networking with up to 12 PCI Express 3.0 lanes, configurable as x1, x2, and x4 depending on motherboard designs. |
PCIe Express 4.0 Interface |
Offers up to 16 GT/s for fast access to peripheral devices and networking with up to 16 PCI Express 4.0 lanes, configurable as x1, x2, and x4 depending on motherboard designs. |
| Modern Manageability with Intel® AMT and Intel® EMA | Allows hardware-based cloud manageability for your entire PC fleet. Lower Total Cost of Ownership with remote management of devices. |
Intel® Integrated 10/100/1000 MAC |
Support for the Intel® Ethernet Connection I219-LM. |
Intel® W680 Chipset Block Diagram4
