Moxa is a leading provider of edge connectivity, industrial computing, and network infrastructure solutions for enabling connectivity for the Industrial Internet of Things. With over 30 years of industry experience, Moxa has connected more than 50 million devices worldwide and has a distribution and service network that reaches customers in more than 70 countries. Moxa delivers lasting business value by empowering industry with reliable networks and sincere service for industrial communications infrastructures.
Offerings
Offering
The V2406C computers are compliant with EN 50155:2017 and EN 50121-4 for railway onboard and wayside applications. Designed for heavy-duty data processing tasks, the V2406C computers are built around an Intel® Core™ i7/i5/i3 or Intel® Celeron® high-performance processor and come with up to 32 GB RAM, one mSATA slot, and two hot-swappable HDD/SSD for storage expansion. For reliable connectivity in train-to-ground (T2G) applications, the computers are provided with two mPCIe wireless expansion slots and four SIM-card slots. These help establish redundant LTE/Wi-Fi connectivity, ensuring solid bidirectional communications between a fast-moving train and the wayside applications. In addition, preinstalled QMA cable for wireless modules can help reduce assembly efforts and ensure low RF leakage. For connecting with onboard and wayside systems and devices, V2406C computers are equipped with a rich set of interfaces including 2 Gigabit Ethernet ports, 4 RS-232/422/485 serial ports, 6 DIs, 2 DOs, and 4 USB 3.0 ports. In addition, the V2406C computers provide 1 VGA video output and 1 HDMI output with 4K resolution support.
Offering
DIN-rail computers with Elkhart Lake Intel Atom® X Series processor base model and high-interface models
Offering
Rackmount 1U computers with Elkhart Lake Intel Atom® X Series processor base model and high-interface models
Offering
Box computers with Elkhart Lake Intel Atom® X Series processor base model and high-interface models
Offering
Box computers with Tiger Lake 11th Gen Intel® Core™ processor base model and high-interface models
Offering
Rackmount 1U computers with Elkhart Lake Intel Atom® X Series processor base model and high-interface models
Offering
IEC 61850-3, IEEE 1613, and IEC 60255 compliant for power substation automation systems EN 50121-4 compliant for railway wayside applications 7th Generation Intel® Xeon® Processor2 Built-in SO-DIMM ECC DDR4 memory slot, up to total 32GB capacity 4 hot-swappable SSD slots; support Intel® RST RAID 0/1/5/10 Highly reliable design, supporting dual power and PRP/HSR technology (with PRP/HSR expansion module)1 PCIe x16, 1 PCIe x4, 2 PCIe x1, and 1 PCI slots for expansion modules Redundant power supply (100 to 240 VAC/VDC)
Offering
The MC-1220 Series rugged edge computers feature high-performance Intel® Core™ i7/i5/i3 processor and multiple expansion interfaces. The expansion interfaces can incorporate hardware accelerators, such as VPUs, and support Intel® OpenVINO™ toolkit for AIoT application development. Designed based on Moxa’s extensive expertise in building rugged computing platforms, the computers can operate in a -40 to 70°C wide operating temperature range and are C1D2/ATEX Zone 2 certified for deployments in outdoor and hazardous environments. In addition, the ultra-compact fanless computers are one of the world’s smallest industrial computers that come with Intel® Core™ i7 processors, making it easy to fit them in small cabinets at field sites. In remote applications, wireless connectivity is required for continuous communications with the control center. MC-1220 Series computers support multiple Wi-Fi/cellular connectivity options, eliminating the need for an additional wireless gateway, thereby saving cost and space. Furthermore, the computing platform features TPM 2.0 technology for enhanced hardware security.
