EEPD (A Trucomp Company) is a market leader of high performance and low power processor boards and systems with technology well suited for Industrial control, Test Equipment, Telecom and Mobile applications. Specializing in rugged industrial grade computers able to sustain extreme conditions, E.E.P.D. delivers time and time again the most advanced and innovative PC/104-Plus processor boards, modules and adapters. With headquarter in Weichs, Germany E.E.P.D. offers ISO 9001:2015 certified in-house Design, Development, full serial production and testing facilities. An expanding product line, clear product migration path, comprehensive services and flexible approach present E.E.P.D. as the ideal Partner for high volume OEM projects and System Integrators.
Offerings
Offering
The industrial PROFIVE® single board computer NUCT was designed in the embedded NUC™ standard and is based on the Intel® Core™ i3, i5 and i7 processors of the 11th generation as well as the Intel® Celeron® processors of the 6000 series.Details:Intel® Core™ i3, i5 and i7 11th generation & Intel® Celeron® 6000 series processors.Intel® UHD graphics for 11th generation Intel® Core™ processors up to Intel® Iris® Xᵉ graphics (variant dependent).Up to 32 GB dual-channel DDR4-3200 SO-DIMM RAM memory; industrial grade variants with in-band ECC2 Intel® I225 2.5 Gbit/s ports with IEEE1588, TSN support as well as Wake-On-Lan (on one port)3 M.2 - Key B, Key E, Key M (2242 NVMe with PCIe x4)Up to 2 SATA (6G) with separate power connectorUp to 5 USB ports: 2x USB 3.1 Gen2 + 1 USB-C 3.1 Gen2 (or DisplayPort++ with image output up to 4096 x 2160 @ 60 Hz) + 2x USB 2.0 (internal)2 RS-232/485 port (HDX/FDX)1 eDP port (max. 4096x2304 @ 60 Hz with backlight control) - OEM/ODM option2 Mini-DP++ Connector up to 4096x2160 @ 60HzTPM 2.0 support with Infineon SLB 9670Min. 8 V to max. 32 V power supply range / automotive grade / terminal 15 supportMax. Operating temperature range: commercial at 0°C to +60°C; industrial -40°C to +85°CMax. Storage temperature range: from -40°C to +85°CMax. rel. humidity: 95% @ 40°C, non-condensingDimensions: approx. 102 mm x 102 mm / embedded NUCSupported operating systems: Microsoft® Windows® 10 / 10 IoT Enterprise, Linux Ubuntu 20.04 LTSDesign, production and support "Made in Germany"Special strengths of NUCT:Extended operating temperature range from -40°C to +85°C (variant-dependent, see CPU list).Long-term availability: Up to 15 years according to CPU manufacturerExtremely strong single-core performance as well as strong multi-core and GPU performance (up to Intel® Iris® Xᵉ graphics / variant-dependent).2 Intel® I225 2.5 Gbit/s ports with IEEE1588, TSN support as well as Wake-On-Lan (on one port)This board is a small, about 4 x 4" (10 x 10 cm), very powerful industrial embedded board. It is ideal for applications that require high CPU performance (especially single core performance) as well as security features such as hardware TPM.These are for example:Robust industrial systems, e.g. with extended temperature rangeAutomation, vending machines, kiosk systems, POSMicro servers, edge servers, IoT applications, gateways, communication applicationsCompact workstationsComputer vision & roboticsMedical applicationsMobile applications in vehicles (integrated automotive grade power supply / KL15 support).And many more.Key features of the NUCT include a RAM of up to 32 GByte DDR4 RAM with in-band ECC (Error Correction Code) (variant dependent), 2x SATA (6G) with separate power connector, 2x NVMe, as well as numerous security features. These include a TPM 2.0 chip as well as health monitoring and management with adjustable fan control, hardware monitoring and watchdog.Different CPUs with a TDP of 12W - 28W (configurable) are used:Temperature range 0°C - +60°CIntel® Celeron® INTC6305E - 2 cores / 2 threads - 1.8 GHz - TDP: 15W Intel® Core™ I3-1115G4E | 2 cores / 4 threads | 2.2 GHz - 3.9 GHz | TDP: 12-28WIntel® Core™ I5-1145G7E | 4 cores / 8 threads | 1.5 GHz - 4.1 GHz | TDP: 12-28WIntel® Core™ I7-1185G7E | 4 cores / 8 threads | 1.8 GHz - 4.4 GHz | TDP: 12-28WTemperature range -40°C - +85°CIntel® Core™ I3-1115GRE | 2 cores / 4 threads | 2.2 GHz - 3.9 GHz | TDP: 12-28WIntel® Core™ I5-1145GRE | 4 cores / 8 threads | 1.5 GHz - 4.1 GHz | TDP: 12-28WIntel® Core™ I7-1185GRE | 4 cores / 8 threads | 1.8 GHz - 4.4 GHz | TDP: 12-28W
Offering
The ENVADER®-MI-BOX is the perfect Plug & Play BoxPC solution for vehicle applications. A high-quality box PC system developed and produced in Germany with high performance and flexibility through a variety of interfaces.The ENVADER®-MI-BOX is an industrial box PC for versatile applications in all types of vehicles.In addition to the numerous standard interfaces, there is the possibility to extend the system by up to 3 interface options.Available CPUs:CPU Intel® Core™ 6 / 7th Gen. processorsi7-7600U / 2.8GHz / 4MB cachei5-7300U / 2.6 GHz / 3 MB cachei3-7100U / 2.4 GHz / 3 MB cacheIntel® Celeron® 3965U / 2.2GHz / 2MB cacheApplication:Mobile Box PC for Commercial/ Industrial Vehicles e.g. for- Fire / Police / Emergency / Special operations- command vehicles- Mobile laboratories- Broadcasting vehiclesRugged Industrial SystemAutomation ControlInformation SystemRemote Measurement & Quality ControlBenefits:Long term availabilityFree of rotating partsRugged & reliable choice for demanding embedded applicationsEasy to expandMade in Germany
Offering
The PROFIVE ® F38 single board computer is powered by Intel Atom® Processors Series E3800. Due to the fact that high performance meets best efficiency the PROFIVE ® F38 panel board is best qualified for fanless applications. The PROFIVE ® F38 SBC opens a broad field of applications in stationary just as well as in mobile devices like measurement instruments, quality control, public terminals, information systems or in rugged industrial environment.
Offering
The Box-PC NUCI is designed in the embedded NUC™ standard and is based on the latest Intel Atom® series E3900 with excellent performance-per-watt performance. This Box-PC is a small, very powerful low-power Box-PC that is suitable for a wide range of applications, such as: Mobile systems, automation, measurement technology, IoT or many other sectors and industries. It is characterized by a wide input voltage range of 8 VDC to 32 VDC as well as a special pre-installation for the vehicle use, including an input for continous plus (Clip 30) and ignition plus (Clip 15). In addition, a special overvoltage protection circuit for vehicle use is implemented, which in particular takes into account load dump scenarios. The EM BoxPC-NUCI is the perfect communication gateway for industrial IoT applications. It is a german engineered and produced high quality Box-PC System.
