congatec AG offers a product portfolio that is comprised of embedded computer modules based on the most common form factors such as Qseven, COM Express and ETX/XTX. congatec also provides professional board support packages, extensive design-in support and specialized embedded BIOS features for industrial use.
Offerings
Offering
Industrial grade SMARC module based on Intel Atom® x7000 Series with up to 8 cores, max. 32 GByte soldered LPDDR5 and Virtualization ready with RTS Hypervisor
Offering
COM Express Type 6 Compact module based on 13th Gen Intel® Core™ embedded mobile processors (code name "Raptor Lake") with soldered down memory.
Offering
COM-HPC Server Size D module based on Intel® Xeon® D processor series (code name "Ice Lake").
Offering
COM-HPC Server Size D high module based on Intel® Ice Lake-D Xeon® processors Industrial Use Condition with extended Temperature options32 PCIe Express lanes AI Capabilities with Intel® DL boost Real Time Capable Platform Supporting up to 256 GB DDR4 2933MT/s Memory
Offering
COM-HPC Client Size A high performance module based on 13th Gen Intel® Core™ processor series (code name "Raptor Lake")
Offering
COM-HPC Client Size C high performance module based on 13th Gen Intel® Core™ processor series (code name "Raptor Lake-S")
Offering
COM Express Type 7 Basic module based on Intel® Ice Lake-D Xeon® Processors ,industrial use condition with extended temperature options 32 PCIe express lanes AI capabilities with Intel® DL boost Real Time Capable Platform.Supporting up to 128 GB DDR4 2666MT/s memory.
Offering
COM-HPC Mini Size high performance module based on 13th Gen Intel® Core™ processor series (code name "Raptor Lake-P")
Offering
COM express type 6 compact module based on 11th Gen Intel® Core™ processor family and soldered down memory
Offering
COM Express Type 6 Compact module based on 12th Gen Intel® Core™ processor family Intel® hybrid design combines Performance-cores with Efficient–cores Up to Intel® Iris® XeGraphics® architecture with up to 96 EUsPCI Express Gen 4 | USB 3.2AI Acceleration with Intel® Deep Learning Boost (VNNI)Embedded Use Condition SKUs.
Offering
The conga-LEKs (Lan Enabling Kits) are mezzanine cards that can be used together with the conga-HPC/Eval-Server evaluation carrier board. These add-on cards enable the user to seamlessly evaluate different ethernet configuration options. The LEKs offer up to 100Gb total throughput and support modern transceiver form factors such as SFP28 and QSFP28.
Offering
COM Express Type 6 Compact module based on 13th Gen Intel® Core™ embedded mobile processors (code name "Raptor Lake")
Offering
COM-HPC Client Size C module based on 12th Gen Intel® Core™ Embedded Desktop Processors Intel® hybrid design combines Performance-cores with Efficient–cores Intel® UHD Graphics 770 driven by Xe Architecture PCI Express Gen 4/5 | USB 3.2 Gen 2x2AI Acceleration based on Intel® Deep Learning Embedded Use Condition SKUs.
Offering
COM-HPC Client Size A module based on 12th Gen Intel® Core™ Embedded mobile Processors Intel® hybrid design combines Performance-cores with Efficient–cores UP to Intel® Iris XeGraphics architecture with up to 96 EUsPCI Express Gen 4 | USB 4AI Acceleration with Intel® Deep Learning Boost (VNNI)Embedded Use Condition SKUs.
Offering
COM HPC Client Size A module based on Intel® (formerly "Tiger Lake")-UP3 high performing and low power Intel® Core™ processor series Form factor COM HPC, Size A (95 x 120 mm), Client Connector Pinout DRAM Up to 2 SO-DIMM sockets for DDR4 memory modules up to 32 GByte each (64 GByte total) with 3200 MT/sECC and non-ECC supported Graphics Integrated Xe (Gen 12) graphics engine with up to 96 EU (Execution Units) | Supporting 4 independent display units (4x 4k/2x 8K) | Enhanced media (AV1/12b) with up to 2 Vdbox | Next Gen IPU6 with DPHY2.1 | HDMI 2.0/2.1 | DP 1.4Display3x DP/HDMI/DP++ | 1x eDPEthernet2x 2,5 GbE TSN Ethernet via Intel® i225I/O Interfaces4x PCIe Gen4 | 8x PCIe Gen32x USB 4.0 | 2x USB 3.22x SATA III (6Gb/s) | SPI | 2x UART | 12x GPIO | 2x MIPI-CSIAudio1x I2S | 2x Sound wirecongatec Board Controller Multi Stage Watchdog | non-volatile User Data Storage | Manufacturing and Board Information | Board StatisticsI²C bus (fast mode, 400 kHz, multi-master) | Power Loss Control | Hardware Health Monitoring | POST Code redirection Embedded BIOS Features OEM Customization | Flash Update | based on AMI Aptio UEFI SecurityTrusted Platform Module (TPM 2.0)Power Management ACPI 5.0 with battery supportSize95 x 120 mm
Offering
Formfactor Qseven Form Factor Rev. 2.0 compliant | 70x70 mmCPUIntel® Atom™ x7-E3950 2.00 GHz (Burst) | 1.6 GHz Clock Quad Core L2 cache 2MB 12W TDPIntel® Atom™ x5-E3940 1.80 GHz (Burst) | 1.6 GHz Clock Quad Core L2 cache 2MB 9W TDPIntel® Atom™ x5-E3930 1.80 GHz (Burst) | 1.3 GHz Clock Dual Core L2 cache 1MB 6.5W TDPIntel® Pentium® N4200 2.50 GHz (Burst) | 1.1 GHz Clock Quad Core L2 cache 2MB 6W TDPIntel® Celeron® N3350 2.40 GHz (Burst) | 1.1 GHz Clock Dual Core L2 cache 1MB 6W TDPFeaturesDRAM: Dual Channel | up to 8GB onboard DDR3L with 1867 MT/sChipset: Integrated in SoCEthernet: Intel® I210 (Industrial) / I211 (Commercial) Gigabit Ethernet ControllerI/O Interfaces: 3x PCIe Gen2 | 1x USB 3.0/2.0 | 5x USB 2.0 | 2x SATA3 | SDv3 | LPC Bus | SMBus | I2C Bus | UARTMass Storage: eMMC 5.0 onboard flash up to 64 GByteSound: Intel® High Definition Audio (Intel® HD Audio)Graphics: Intel® Gen 9 LP Graphics supporting DirectX 12 | OpenGL 4.3 | OpenCL 2.0 | OpenGL ES 3.0 | HW accelerated video decoding HEVC/H.264/MVC/MPEG2/VP9/VC-1/WMV9/MJPEG and encoding HEVC/H.264/MVC/VP8/MJPEG | Content protection using PAVP 2.0 and HDCP 1.4/2.2LVDS: 18/24-bit Single/Dual Channel LVDS Interface, resolutions up to 1920X1200@60Hz | VESA standard or JEIDA data mapping Automatic Panel Detection via EDID/EPI | shared with eDP 1.3 supporting up to 3840x2160@60 Hz (option)DisplayPort Interface (DDI): DisplayPort 1.2 up to 4096×2160@60Hz or HDMI 1.4b up to 3840×2160@30HzMIPI-CSI: 1x MIPI-CSI x4 and 1x MIPI-CSI x2congatec Board controller: Multistage watchdog | non-volatile user data storage | manufacturing and board Information | board statistics I²C bus (fast mode | 400 kHz | multi master) | power loss controlEmbedded BIOS Features: AMI Aptio® UEFI 2.x firmware | 8 MByte serial SPI with congatec Embedded BIOS features OEM Logo | OEM CMOS Defaults | LCD Control Display Auto Detection | Backlight Control | Flash UpdatePower Management: ACPI 5 .0 compliant | Smart Battery ManagementOperating Systems: Microsoft® Windows 10 | LinuxPower Consumption: Typ. application 6W...12WTemperature: Commercial : Operating: 0 to +60°C Storage: -20 to +70°CIndustrial: Operating: -40 to +85°C Storage: -40 to +85°CHumidity: Operating: 10 to 90% r. H. non cond.Storage: 5 to 95% r. H. non cond.Size: 70 x 70 mm (2¾” x 2¾”)
Offering
Codename "Denverton"COM Express Type 7 Basic module based on the latest Intel Atom® C3000 processor series FormfactorCOM Express BasicCPUIntel® Atom™ C3958 (16 x 2.0 GHz, 16MB cache , 31 W)Intel® Atom™ C3858 (12x 2.0 GHz , 12MB cache, 25W)Intel® Atom™ C3758 (8x 2.2 GHz, 16MB cache, 25W)Intel® Atom™ C3558 (4x 2.2 GHz, 8MB cache, 16W)Intel® Atom™ C3538 (4x 2.1 GHz, 8MB cache, 15W)Intel® Atom™ C3808 (12x 2.0 GHz, 12MB cache, 24W)Intel® Atom™ C3708 (8x 1.7 GHz, 16MB cache, 17W )Intel® Atom™ C3508 (4x 1.5 GHz, 8MB cache, 11)DRAMup to 3 SO-DIMM sockets for DDR4 memory modules up to 16 GByte each (48 GByte total) with 2400 MT/s | ECC and non-ECC supportedChipsetIntegrated in SoCEthernet4x 10GbE with KR interface supportI/O Interfaces12 x PCI Express GEN 3.0 lanes8 x PCIe Gen22 x USB 3.04 x USB 2.02 x SATA IIILPC busSPI2 x UARTSM-Buscongatec Board ControllerMulti Stage Watchdog | non-volatile User Data Storage | Manufacturing and Board Information | Board Statistics | LVDS backlight control I²C bus (fast mode, 400 kHz, multi-master) | Power Loss Controlembedded BIOS FeaturesOEM LogoOEM CMOS DefaultsFlash UpdateAMI Aptio UEFISecurityTrusted Platform Module (TPM) optional. Hash and RSA algorithms, key lengths up to 2,048 bits, real random number generatorPower ManagementACPI 5 .0 compliant, Smart Battery ManagementOperating SystemsMicrosoft® Windows 10 EnterpriseMicrosoft® Windows® 8.1Microsoft® Windows® 7Microsoft® Windows Server 2016Fedora 22Ubuntu 14.10CentOS 6.6 & 7.1FreeBSD 10.3 & 11VMwareMicrosoft® Windows Server 2012 R2Microsoft® Windows Server 2012Microsoft® Windows Server 2008 R2 SP1RHEL 6.6 & 7.1SuSE 11 SP4 & 12 SP1Yocto v.2.0 Kernel 4.1Wind River VxWorks 7ESXiRTS Hypervisor
Offering
Industrial Thin Mini-ITX based on 5th Generation Intel® Atom™, Intel® Celeron® and Pentium® ProcessorsIntel® 5th Gen. Atom™, Celeron® and Pentium® ProcessorsLow Power CPUs 6 to 12 Watt TDPEnhanced Intel® HD Graphics Generation 9Long life components for 24/7 embedded useExtended Temperature variants
Offering
conga-TS370COM Express Type 6 Basic module based on the latest Intel® processor series (formerly Coffee Lake) 8th Generation Intel® Core™ processorwith up to 6 CoresIntel® Xeon® processors for data center applicationsSupport for USB 3.1 Gen2 with 10Gb/sIntel® Optane™ memory supportECC memory supportUp to 32 GByte dual channel DDR4 memory
Offering
Highest Performance 3.5'' Single Board Computer based on 8th Generation Intel® Core™ processor series called "Whiskey Lake"Highest Performance 3.5'' Single Board Computer8th Generation Intel® Core™ Mobile Low Power U-Processors with up to 4 coresGen 9 Intel Graphics, up to 24 Execution UnitsMultiple Expansion card possibilitiesOption for 2nd internal video interface
Offering
Highest Performance Thin-Mini-ITX board based on 8th Generation Intel® Core™ Mobile Processors "Whiskey Lake"Highest Performance Thin Mini-ITX board8th Generation Intel® Core™ MobileLow Power U-Processors with up to 4 coresGen 9 Intel Graphics, up to 24EUOptions for 2nd internal displayWide Range Power Input 12-24 Voltcongatec embedded Board Controller Features
Offering
COM Express Type 6 Compact module based on 8th Generation Intel® Core™ processor family8th Generation Intel® Core™ SOC processorup to 4 coresConfiguration of display mode by software (LVDS/eDP)Low power consumption (TDP 15W, cTDP 10W)Up to 64 GByte dual channel DDR4 2400 MT/sOptional eMMC 5.1 on board mass storageTrusted Platform Module (TPM 2.0)
Offering
Ready for Intel® Optane™ memory technology FormfactorCOM Express CompactCPUIntel® Core™ i7-7600U (2 x 2.8 / 3.9 GHz, 4MB Cache, 15W)Intel® Core™ i5-7300U (2 x 2.6 / 3.5 GHz, 3MB Cache, 15W)Intel® Core™ i3-7100U (2 x 2.4 GHz, 3MB Cache, 15W)Intel® Celeron® 3965U (2 x 2.2 GHz, 2MB Cache, 15W)DRAM2 Sockets, SO-DIMM DDR4 up to 2133 MT/s and 32 GByte dual channelChipsetIntegrated PCH-LPEthernetIntel® i219-LM GbE LAN Controller with AMT 11.6 supportI/O Interfaces8 x PCI Express GEN 3.0 lanesIntel® Optane™ memory can be connected via PCI Express Gen 3.03 x Serial ATA® Gen 3 (can be configured as RAID)4 x USB 3.0 (XHCI)8 x USB 2.0 (XHCI)LPC bus (no DMA)I²C bus (fast mode, 400 kHz, multi-master) 2 x UARTSoundDigital High Definition Audio Interface with support for multiple audio codecsGraphicsIntel® Gen9 HD Graphics Engine OpenCL 2.1, OpenGL 5.0 and DirectX12 (for Windows 10) support | up to three independent displays: HDMI 1.4a / DisplayPort 1.2 / eDP 1.3 | High performance hardware MPEG-2 decoding | WMV9 (VC-1) and H.265 (HEVC) support Blu-ray support @ 40 MBit/s | HEVC, VP9 and VDENC encodingcongatec Board ControllerMulti Stage Watchdog | non-volatile User Data Storage | Manufacturing and Board Information | Board Statistics | LVDS backlight control I²C bus (fast mode, 400 kHz, multi-master) | Power Loss Controlembedded BIOS FeaturesAMI AptioV® UEFI 2.x firmware8/16 MByte serial SPI firmware flashSecurityThe conga-TC175 can be optionally equipped with a discrete ”Trusted Platform Module” (TPM 1.2 / 2.0). It is capable of calculating efficient hash and RSA algorithms with key lengths up to 2,048 bits and includes a real random number generator. Security sensitive applications such as gaming and e commerce will benefit also with improved authentication, integrity and confidence levels.Power ManagementACPI 4.0 with battery supportOperating SystemsMicrosoft® Windows 10 (64bit only)Fedora 24UbuntuSuSeRed Hat EnterpriseYocto Project v2.2Chromium 2Wind River VxWorksMicrosoft® Windows 10 IoT Enterprise (64bit only)Power ConsumptionSee User's Guide for full detailsTemperatureStandardOperating: 0 to +60°CStorage: -20 to +80°CHumidityOperating: 10 to 90% r. H. non cond. / Storage 5 to 95% r. H. non cond.Video Interfaces2x TMDS (HDMI) / DisplayPort 1.2 with support for Multi-Stream Transport (MST) | resolutions up to 4k | VGA (optional)Dual channel LVDS transmitter, Supports flat panels 2x24 Bit interface | VESA and openLDI colour mappings | resolutions up to 1920x1200 Automatic Panel Detection via EDID/EPISize95 x 95 mm (3,74" x 3,74")
Offering
Ready for Intel® Optane™ memory technology FormfactorCOM Express BasicCPUIntel® Core™ i7-7820EQ (4 x 3.0 / 3.7 GHz, 8MB Cache, 45W)Intel® Core™ i5-7440EQ (4 x 2.9 / 3.6 GHz, 6MB Cache, 45W)Intel® Core™ i5-7442EQ (4 x 2.1 / 2.9 GHz, 6MB Cache, 25W)Intel® Core™ i3-7100E (2 x 2.9 GHz, 3MB Cache, 35W)Intel® Core™ i3-7102E (2 x 2.1 GHz, 3MB Cache, 25W)Intel® Xeon® E3-1505M V6 (4 x 3.0 / 4.0 GHz, 8MB Cache, 45W)Intel® Xeon® E3-1505L V6 (4 x 2.2 / 3.0 GHz, 8MB Cache, 25W)DRAM2 Sockets, SO-DIMM DDR4 up to 2400 MT/s and 32GByte dual channel, optionally with ECC supportChipsetMobile Intel® 100 Series ChipsetEthernetIntel® i219-LM GbE LAN Controller with AMT 11.6 supportI/O Interfaces8 x PCI Express GEN 3.0 lanesIntel® Optane™ memory can be connected via PCI Express Gen 3.04 x Serial ATA Gen 34 x USB 3.0 (XHCI)8 x USB 2.0 (XHCI)1 x PEG x16 Gen 3LPC busI²C bus (fast mode, 400 kHz, multi-master) 2 x UARTSoundDigital High Definition Audio Interface with support for multiple audio codecsGraphicsIntel® Gen9 HD Graphics Engine OpenCL 2.1, OpenGL 5.0 and DirectX12 (for Windows 10) support | up to three independent displays: HDMI 1.4a / DisplayPort 1.2 / eDP 1.3 | High performance hardware MPEG-2 decoding | WMV9 (VC-1) and H.265 (HEVC) support Blu-ray support @ 40 MBit/s | HEVC, VP9 and VDENC encodingcongatec Board ControllerMulti Stage Watchdog | non-volatile User Data Storage | Manufacturing and Board Information | Board Statistics | LVDS backlight control I²C bus (fast mode, 400 kHz, multi-master) | Power Loss Controlembedded BIOS FeaturesAMI AptioV® UEFI 2.x firmware8/16 MByte serial SPI firmware flashSecurityThe conga-TS175 can be optionally equipped with a discrete ”Trusted Platform Module” (TPM 1.2 / 2.0)Power ManagementACPI 4.0 with battery supportOperating SystemsMicrosoft® Windows 10 (64bit only)Microsoft® Windows 10 IoT Enterprise (64bit only) LinuxFedora 24UbuntuSuSeRed Hat EnterpriseYocto Project v2.2Chromium 2Wind River VxWorksPower ConsumptionSee User's Guide for full detailsTemperatureStandardOperating: 0 to +60°CStorage: -20 to +80°CHumidityOperating: 10 to 90% r. H. non cond. / Storage 5 to 95% r. H. non cond.Video Interfaces3x TMDS (HDMI) / DisplayPort 1.2 with support for Multi-Stream Transport (MST) | resolutions up to 4k | VGA (optional)Dual channel LVDS transmitter, Supports flat panels 2x24 Bit interface | VESA and openLDI colour mappings | resolutions up to 1920x1200 Automatic Panel Detection via EDID/EPISize95 x 125 mm (3.74" x 4.92")
Offering
FormfactorCOM Express® Compact | (95 x 95 mm) | Type 6 Connector LayoutCPU Intel® Pentium® N4200 2.50 GHz (Burst) | 1.1 GHz Clock Quad Core L2 cache 2MB 6W TDPIntel® Celeron® N3350 2.40 GHz (Burst) | 1.1 GHz Clock Dual Core L2 cache 1MB 6W TDPIntel® Atom™ x7-E3950 2.00 GHz (Burst) | 1.6 GHz Clock Quad Core L2 cache 2MB 12W TDPIntel® Atom™ x5-E3940 1.80 GHz (Burst) | 1.6 GHz Clock Quad Core L2 cache 2MB 9W TDPIntel® Atom™ x5-E3930 1.80 GHz (Burst) | 1.3 GHz Clock Dual Core L2 cache 1MB 6.5W TDPFeaturesDRAM: 2 SO-DIMM sockets for DDR3L memory modules up to 8 GByte with 1867 MT/s | Dual channel memory interface for increased graphics performanceChipset: Integrated in SoCEthernet: Intel I210 (Industrial) /I211 (Commercial) Gigabit Ethernet Controller with SDP supportI/O Interfaces: 5x PCIe x1 | 4x USB 3.0 (XHCI) | 8x USB 2.0 (EHCI) | 2x SATA III | LPC | SPI | I²C bus (fast mode 400 kHz | multi-master) | SDIO 2x UART (RX/TX)s | 2x MIPI-CSIMass Storage: eMMC 5.0 onboard flash up to 64 GByteSound: Digital High Definition Audio InterfaceGraphics: Intel® HD Graphics Gen 9 | PAVP 2.0 | H.265/HEVC | VP9 | OpenCL 2.0 | OpenGL 4.3 | OpenGL ES 3.0 | DirectX12 | HDCP1.4LVDS: Dual channel LVDS transmitter | support for flat panels with 2x24 bit data mapping up to a resolution of 1920x1200@60Hz.Digital Display Interface (DDI): Up to 2x DisplayPort 1.2a or 2x HDMI 1.4b (max. 3840x2160 @ 30Hz) | 1x eDP 1.3 (optional)congatec Board Controller: Multi Stage Watchdog | non-volatile User Data Storage | Manufacturing and Board Information | Board Statistics | BIOS Setup Data Backup I²C bus (fast mode, 400 kHz, multi-master) | Power Loss ControlEmbedded BIOS Features: OEM Logo | OEM CMOS Defaults | LCD Control | Display Auto Detection | Backlight Control | Flash Update | based on AMI Aptio UEFISecurity: Trusted Platform Module (TPM) optional. Hash and RSA algorithms | key lengths up to 2048 bits | real random number generatorPower Management: ACPI 5.0 with battery supportOperating Systems: Microsoft® Windows 10 | LinuxPower Consumption: see user’s guide for full details | CMOS Battery BackupTemperature:Commercial : Operating: 0 to +60°C Storage: -20 to +80°CIndustrial: Operating: -40 to +85°C Storage: -20 to +80°CHumidity: Operating: 10 - 90% r. H. non cond. Storage: 5 - 95% r. H. non cond.Size: 95 x 95 mm (3.74” x 3.74”)
Offering
Formfactor Pico-ITX Singleboard Computer CPU Intel® Atom™ x7-E3950 2.00 GHz (Burst) | 1.6 GHz Clock Quad Core L2 cache 2MB 12W TDPIntel® Atom™ x5-E3940 1.80 GHz (Burst) | 1.6 GHz Clock Quad Core L2 cache 2MB 9W TDPIntel® Atom™ x5-E3930 1.80 GHz (Burst) | 1.3 GHz Clock Dual Core L2 cache 1MB 6.5W TDPIntel® Pentium® N4200 2.50 GHz (Burst) | 1.1 GHz Clock Quad Core L2 cache 2MB 6W TDPIntel® Celeron® N3350 2.40 GHz (Burst) | 1.1 GHz Clock Dual Core L2 cache 1MB 6W TDPDRAMMemory up to 4 Channels onboard LPDDR4 (V1.1) with up to 2400 MT/s | max. 8 GBChipsetIntegrated in SoCEthernet2x LAN Gbit / 100 Mbit / 10 Mbit | Intel Gigabit Ethernet i211 controller (i210 for industrial temperature)SoundHigh Definition Audio Interface | Cirrus Logic CS4207GraphicsIntel® Gen 9 HD Graphics with support for DirectX12 | OpenGL 4.3 | OpenCL 2.0 | OpenGLES 3.x | MPEG2 full HW acceleration with H.265/HEVC decoding and H.264 encoding | VP9 | PAVP 3.x | HDCP 1.4 | MVC and 2x independent display support in 4K (3840 x 2160 px) @30 Hz or WQXGA (2560 x 1600 px) @60 HzGraphic Interfaces1x 18/24-bit Single/Dual Channel LVDS Interface (via eDP to LVDS converter PTN3460) | 1x DisplayPort DP++ | resolution up 1920x1200 with 60Hz up to 4096x2160 @ 60Hz with eDPInternal Connectors 1x miniPCIe or mSATA full size | 1x SATA (6G) (with auxiliary +5V power connector for 2.5" HDD)2x USB 2.0 | 1x LVDS 2x24bit | 1x Backlight power connector | 1x Line Out | 1xMic In | 1x S/PDIF Out | 1x Power In (+12V) 2x COM (RS232 / RS-485 / RS422) | 1x Fan Connector | 3x Feature Connector | micro SD Card | MIPI-CSI 2.0External Connectors(Frontpanel)1x DisplayPort DP++ | 2x LAN RJ45 | 1x USB 3.0 Type C (with PD and DP++) | 2x USB 3.0 | 1x DC-In (only for commercial variants)congatec embedded ControllerMulti-Stage Watchdog | non-volatile User Data Storage | Manufacturing and Board Information | Board Statistics | BIOS Setup Data Backup I²C bus (fast mode | 400 kHz | multi-master) | Power Loss ControlEmbedded BIOSAMI Aptio® 2.X (UEFI) BIOS; SM-BIOS | BIOS Update | Logo Boot | Quiet Boot | HDD PasswordPower Specification Power Supply 12V | RTC batteryOperating SystemsMicrosoft® Windows 10 | Microsoft® Windows 10 IoT | Linux (Wind River, Yocto) | Android | Wind River VxWorksOperating Temperature:Operating: Commercial: 0 .. +60°C Storage: Commercial: -40 .. +70°CIndustrial: -40 + 85°C Industrial: -40 + 85°CHumidity Operating:Operating: 10 - 90% r. H. | Storage: 5 - 95% r.H.Size 100 x 72 mm (3.9” x 2,8”)
Offering
FormfactorSMARC Specification 2.0 | 82x50 mmCPUIntel® Atom™ x7-E3950 2.00 GHz (Burst) | 1.6 GHz Clock Quad Core L2 cache 2MB 12W TDPIntel® Atom™ x5-E3940 1.80 GHz (Burst) | 1.6 GHz Clock Quad Core L2 cache 2MB 9W TDPIntel® Atom™ x5-E3930 1.80 GHz (Burst) | 1.3 GHz Clock Dual Core L2 cache 1MB 6.5W TDPIntel® Pentium® N4200 2.50 GHz (Burst) | 1.1 GHz Clock Quad Core L2 cache 2MB 6W TDPIntel® Celeron® N3350 2.40 GHz (Burst) | 1.1 GHz Clock Dual Core L2 cache 1MB 6W TDPFeaturesDRAM: up to 8GB onboard LPDDR4 with 2400MT/sChipset: Integrated in SoCEthernet: up to 2x Intel® I210 (Industrial) /I211 (Commercial) Gigabit Ethernet Controller with SDP support | 2x Real Time TriggerI/O Interfaces: 2x USB3.0 | 4x USB2.0 | 1x SATA3 | 1x SDIO | up to 4x PCIe Gen2 | 2x I²C Bus | 2x SPI I 4x UART | optional M.2 1216 WiFi module (soldered down)Mass Storage: eMMC 5.0 onboard flash up to 64 GByteSound: Intel® High Definition Audio (Intel® HD Audio) Integrated Audio DSP with Intel® Smart Sound TechnologyGraphics: Intel® Gen 9 HD Graphics with support for DirectX 12 | OpenGL 4.3 | OpenCL 2.0 | OpenGL ES 3.0 | MPEG2 full HW acceleration with H.265/HEVC decoding and encoding | MVC and 2x independent display support in 4K | VP9 | PAVP 2.0 | HDCP 1.4 (wired), HDCP 2.0 (wireless)LVDS: Dual channel LVDS transmitter | support for flat panels with 2x24 bit data mapping up to a resolution of 1920x1200 @60Hz | shared with eDP or 2x MIPI-DSI x4 (option)DisplayPort Interface (DDI): DisplayPort 1.2 up to 4096x2160px or HDMI 1.4b up to 3840x2160pxMIPI-CSI: 1x MIPI-CSI x4 and 1x MIPI-CSI x2congatec Board controller: Multistage watchdog | non-volatile user data storage | manufacturing and board Information | board statistics I²C bus (fast mode | 400 kHz | multi master) | power loss controlEmbedded BIOS Features: AMI Aptio® UEFI 2.x firmware | 8 MByte serial SPI with congatec Embedded BIOS features OEM Logo | OEM CMOS Defaults | LCD Control Display Auto Detection | Backlight Control | Flash UpdatePower Management: ACPI 5 .0 compliant | Smart Battery ManagementOperating Systems: Microsoft® Windows 10 | Microsoft® Windows IoT Core | Linux | Android 6.0 | VxWorks 7.0Power Consumption: Typ. application: tbd. | see manual for full detailsTemperature:Commercial : Operating: 0 to +60°C Storage: -20 to +80°CIndustrial: Operating: -40 to +85°C Storage: -40 to +70°CHumidity: Operating: 10 to 90% r. H. non cond. Storage: 50 to 95% r. H. non cond.Size: 82 x 50 mm (3,23” x 1,97”)
Offering
FormfactorCOM Express BasicCPUIntel® Xeon® D1577 (16 x 1.3 / 2.1 GHz, 25MB cache, 45 W)Intel® Xeon® D1548 (8 x 2.0 / 2.6 GHz, 12MB cache, 45 W)Intel® Xeon® D1527 (4 x 2.2 / 2.7 GHz, 6MB cache, 35 W)Intel® Pentium™ D1509 (2 x 1.5 GHz, 3MB cache, 19 W)Intel® Pentium™ D1508 (2 x 2.2 / 2.6 GHz, 3MB cache, 25 W )Intel® Xeon® D1559 (12 x 1.5 / 2.1 GHz, 18MB cache, 45 W)Intel® Xeon® D1539 (8 x 1.6 / 2.2 GHz, 12MB cache, 35 W)Intel® Xeon® D1529 (4 x 1.3 GHz, 6MB cache, 20 W)Intel® Pentium™ D1519 (4 x 1.5 / 2.1 GHz, 6MB cache, 25 W)DRAMup to 3 SO-DIMM sockets for DDR4 memory modules up to 16 GByte each (48 GByte total) with 2400 MT/s | ECC and non-ECC supportedChipsetIntegrated in SoCEthernet1x Intel I210AT /IT Gigabit Ethernet Controller | 2x 10GbE with KR interface support - the 10GbE PHY must be implemented on the carrier boardI/O Interfaces24 x PCI Express GEN 3.0 lanes8 x PCI Express 2.04 x USB 2.02 x SATA IIILPC busSPII²C bus2 x UARTcongatec Board ControllerMulti Stage Watchdog | non-volatile User Data Storage | Manufacturing and Board Information | Board Statistics | LVDS backlight control I²C bus (fast mode, 400 kHz, multi-master) | Power Loss Controlembedded BIOS FeaturesOEM LogoOEM CMOS DefaultsFlash UpdateAMI Aptio UEFISecurityTrusted Platform Module (TPM) optional. Hash and RSA algorithms, key lengths up to 2,048 bits, real random number generatorPower ManagementACPI 5 .0 compliant, Smart Battery ManagementOperating SystemsMicrosoft® Windows 10 EnterpriseMicrosoft® Windows® 8.1Microsoft® Windows® 7Microsoft® Windows Server 2016Fedora 22Ubuntu 14.10CentOS 6.6 & 7.1FreeBSD 10.3 & 11VMwareMicrosoft® Windows Server 2012 R2Microsoft® Windows Server 2012Microsoft® Windows Server 2008 R2 SP1RHEL 6.6 & 7.1SuSE 11 SP4 & 12 SP1Yocto v.2.0 Kernel 4.1Wind River VxWorks 7ESXiTemperatureStandardOperating: 0 to +60°CStorage: -20 to +80°CHumidityOperating: 10 to 90% r. H. non cond. / Storage 5 to 95% r. H. non cond.Size95 x 125 mm (3.74" x 4.92")
Offering
FormfactorCOM Express MiniCPUIntel® Atom™ x7-E3950 (4 x 1.6 / 2.0 GHz, 2MB L2 cache, 12W)Intel® Atom™ x5-E3940 (4 x 1.6 / 1.8 GHz, L2 cache 2MB, 9W)Intel® Atom™ x5-E3930 (2 x 1.3 / 1.8 GHz, L2 cache 1MB, 6.5W)Intel® Pentium® N4200 (4 x 1.1 / 2.5 GHz, L2 cache 2MB, 6W)Intel® Celeron® N3350 (2 x 1.1 / 2.4 GHz, L2 cache 1MB, 6W)DRAMDual channel onboard DDR3L memory support for up to 8 GByte at 1866MT/sChipsetIntegrated in SoCEthernetIntel® I210 (Industrial) / I211 (Commercial) Gigabit Ethernet ControllerI/O Interfaces4 x PCIe Gen22 x USB 3.06 x USB 2.02 x SATA3SDIOLPC busSM-BusI²C bus2 x UARTSoundHigh Definition Audio InterfaceGraphicsIntel® HD Graphics Gen 9 | PAVP 2.0 | H.265/HEVC | VP9 | OpenCL 2.0 | OpenGL 4.3 | OpenGL ES 3.0 | DirectX12 | HDCP1.4congatec Board ControllerMulti Stage Watchdog | non-volatile User Data Storage | Manufacturing and Board Information | Board Statistics | LVDS backlight control I²C bus (fast mode, 400 kHz, multi-master) | Power Loss Controlembedded BIOS FeaturesAMI AptioV® UEFI 2.x firmware8 MByte serial SPI firmware flashOEM LogoOEM CMOS DefaultsLCD ControlDisplay Auto DetectionBacklight ControlFlash UpdateSecurityInfineon’s Trusted Platform Module (TPM 2.0/1.2) SLB 9665/9660 optionPower ManagementACPI 5 .0 compliant, Smart Battery ManagementOperating SystemsMicrosoft® Windows 10 EnterpriseMicrosoft® Windows IoT CoreLinuxAndroidPower ConsumptionTyp. application <10 WattTyp. application <10 W @ 5 V, CMOS Battery BackupTemperatureStandard Operating: 0 to +60°CStorage: -20 to +80°CHumidityOperating: 10 to 90% r. H. non cond. / Storage 5 to 95% r. H. non cond.Size55 x 84 mm (2.17" x 3.31")
Offering
Ready for Intel® Optane™ memory technology FormfactorMini ITXCPUIntel® Core™ i5-7300U (2 x 2.6 / 3.5 GHz, 3MB Cache, 15W)Intel® Core™ i3-7100U (2 x 2.4 GHz, 3MB Cache, 15W)Intel® Celeron® 3965U (2 x 2.2 GHz, 2MB Cache, 15W)Intel® Core™ i7-7600U (2 x 2.8 / 3.9 GHz, 4MB Cache, 15W)DRAMSupport for 2x SO DIMM Socket (dual channel DDR4 up to 2133 MT/s), max. 2x 16GBChipsetIntegrated in SoCEthernetDual LAN Gbit / 100 Mbit / 10 Mbit; 1x Intel® Gigabit Ethernet PHY i219LM (with AMT support); 1x Intel ®Gigabit Ethernet Controller i211 (i210 optional)Internal Connectors1x PCIe x4 slot (gen3)1x Full/Half-size Mini PCIe slotM.2 key B 2242/3042 connector (2x PCIe lanes for Intel® Optane™ memory support)3x SATA (6G), one shared with M.21x SATA Power4x USB 2.01x LVDS (2x24 bit)1x Embedded DisplayPort (x4)1x Backlight (Power, control)1x Monitor OFF1x Surround1x Front Panel HD Audio1 x Digital MIC or S/PDIF1x Internal stereo speaker2x Serial Port COM2 (opt. as ccTALK)1x Feature connector - congatec custom (8 Bit General Purpose I/O)Connector for Integrated Sensor Hub1x Frontpanel (Power Switch, LEDs, Reset)1x Intrusion (Case Open),1x FAN CPU1x FAN System1x internal power header (12-24V)1x CEC1x microSIM card slot1x microSD card slot1x opt. battery header signal + power (SBM3)1x I²C BusExternal Connectors2x DisplayPort dp++Audio InLine Out2x LAN RJ454x USB 3.0/2.01x DC-In (external input) 12-24 Vcongatec Board ControllerMulti Stage Watchdog | non-volatile User Data Storage | Manufacturing and Board Information | Board Statistics | LVDS backlight control I²C bus (fast mode, 400 kHz, multi-master) | Power Loss Controlembedded BIOS FeaturesAMI Aptio UEFISM-BIOSBIOS UpdateLogo BootQuiet BootHDD PasswordSecurityThe conga-IC175 can be optionally equipped with a discrete ”Trusted Platform Module 2.0”t is capable of calculating efficient hash and RSA algorithms with key lengths up to 2048 bits and includes a real random number generator.Power ManagementPower Management | ACPI S3/S4 DeepSx | Wake on time from S5 | Power Supply 12-24 V | 2x fan (CPU / system) monitored & controlledOperating SystemsMicrosoft® Windows 10 (64bit only)Microsoft® Windows 10 IoT Enterprise (64bit only) LinuxPower ConsumptionSee User's Guide for full detailsTemperatureOperating: 0 to +60°C Storage: -20 to +70°CHumidityOperating: 10 - 90% r. H. non cond.Size170 x 170 mm (6.7” x 6.7”)
Offering
COM Express Type 6 Basic module based on 11th Generation Intel® Core™ processor family Embedded/Industrial use condition Extended temperature options available PCI Express Gen 4 AI/DL Instruction Sets including VNNI Optional onboard NVMe SSD Integrated Xe (Gen 12) graphics with 32 EU
Offering
COM-HPC high performance module based on 11th Gen Intel® Core™ processor series (code name "Tiger Lake-H") Embedded/Industrial use condition Extended temperature options available PCI Express Gen 4 | USB 4.0 AI/DL Instruction Sets including VNNI Up to 128 Gbyte DDR4-3200 MT/s Integrated Xe (Gen 12) graphics with 32 EU
Offering
COM Express Type 6 Basic module based on 11th Generation Intel® Core™ processor family Embedded/Industrial use condition Extended temperature options available PCI Express Gen 4 AI/DL Instruction Sets including VNNI Optional onboard NVMe SSD Integrated Xe (Gen 12) graphics with 32 EU
Offering
COM Express Type 6 Compact based on Intel® Atom® x6000E, Intel® Pentium® and Celeron® J processor series High performance Intel® UHD Graphics (Gen11) Options for Industrial Temperature Range -40°C to 85°C Time Sensitive Networking and Time Coordinated Computing for improved Realtime Capability Up to 4.267 MT/s onboard Memory Support with Inband ECC UFS 2.0 for higher bandwidth and data processing (optional)
Offering
COM Express® Mini Type 10 module based on Intel® Atom® x6000E, Intel® Pentium® and Celeron® J processor series High performance Intel® UHD Graphics (Gen11) Options for Industrial Temperature Range -40°C to 85°C Time Sensitive Networking and Time Coordinated Computing for improved Realtime Capability Up to 4.267 MT/s onboard Memory Support with Inband ECC UFS 2.0 for higher bandwidth and data processing
Offering
Qseven module based on Intel® Atom® x6000E, Intel® Pentium® and Celeron® J processor series High performance Intel® UHD Graphics (Gen11) Options for Industrial Temperature Range -40°C to 85°C Time Sensitive Networking and Time Coordinated Computing for improved Realtime Capability Up to 4.267 MT/s onboard Memory Support with Inband ECC UFS 2.0 for higher bandwidth and data processing Form Factor Qseven Form Factor | Qseven Spec. Rev. 2.1 compliant | 70 x 70 mm DRAM max. 16GB onboard LPDDR4x | up to 4.267 MT/s Ethernet Intel® GbE with TSN support and Out-Of-Band Management | real-time trigger I/O Interfaces 2x USB SuperSpeedPlus extentsion | up to 8x USB 2.0 (1x OTG) | 2x SATA III | 1x SDIO | 4x PCIe Gen3 | I²C Bus | SMBus | 1x SPI | UART | CAN | LPC | Mass Storage UFS 2.1 onboard flash up to 64 Gbyte Sound HD Audio Intel® LPE Audio via I2S Graphics Intel® HD Graphics LVDS Dual channel LVDS transmitter | support for flat panels with 2x24 bit data mapping up to a resolution of 1920x1200 @60Hz | shared with eDP or MIPI-DSI x4 (option) DisplayPort Interface (DDI) DisplayPort 1.4 4096x2160px @60Hz or HDMI 2.0 4096+2160px @60Hz congatec Board controller Multistage watchdog | non-volatile user data storage | manufacturing and board Information | board statistics | fast mode and multi-master I²C bus | power loss control Embedded BIOS Feature AMI Aptio® UEFI firmware | 32 MByte serial SPI with congatec Embedded BIOS features OEM Logo | OEM CMOS Defaults | LCD Control | Display Auto Detection | Backlight Control | Flash Update Power Management ACPI 5 .0 compliant | Smart Battery Management Operating Systems Microsoft® Windows 10 | Microsoft® Windows 10 IoT Enterprise | Microsoft® Windows IoT 10 Core | Linux (Yocto Project) | Android | RTS Hypervisor Power Consumption Typ. Application: see manual for full details Temperature Range Commercial: Industrial: Operating Temperature: 0 to +60°C Operating Temperature: -40 to +85°C Storage Temperature: -20 to +80°C Storage Temperature: -40 to +85°C Humidity Operating Humidity: 10 to 90% r. H. non cond. Storage Humidity: 5 to 95% r. H. non cond. Size Qseven 70 x 70 mm (approx. 2.75” x 2.75”)
Offering
SMARC 2.1 module based on Intel® Atom® x6000E and Intel® Pentium® and Celeron® J Series processors High performance Intel® UHD Graphics (Gen11) Options for Industrial Temperature Range -40°C to 85°C Time Sensitive Networking and Time Coordinated Computing for improved Realtime Capability Up to 4.267 MT/s Memory Support with Inband ECC UFS 2.0 for higher bandwidth and data processing Product Video Form Factor SMARC Specification 2.1 | 82x50 mm DRAM max. 16GB onboard LPDDR4x with up to 4.267 MT/s Ethernet 2x Intel® GbE with TSN support and Out-Of-Band Management | 2x real-time trigger I/O Interfaces 2x USB 3.0 (1x OTG) | 6x USB 2.0 (1x OTG) | 1x SATA III | 1x SDIO | up to 4x PCIe Gen3 | 2x I²C Bus | 1x SPI I 1x eSPI | 4x UART | GPIO | 2x CAN | 1x I2S | onboard M.2 1216 WiFi/BT module (optional) Mass Storage UFS 2.1 onboard flash up to 64 Gbyte (optional up to 512 Gbyte) Sound Intel® LPE Audio via I2S Graphics Intel® HD Graphics LVDS Dual channel LVDS transmitter | support for flat panels with 2x24 bit data mapping up to a resolution of 1920x1200 @60Hz | shared with eDP or 1x MIPI-DSI x4 (option) DisplayPort Interface (DDI) DisplayPort 1.2 up to 4096x2160px and HDMI 1.4b up to 3840x2160px congatec Board controller Multistage watchdog | non-volatile user data storage | manufacturing and board Information | board statistics | fast mode and multi-master I²C bus | power loss control Embedded BIOS Feature AMI Aptio® UEFI firmware | 32 Mbyte serial SPI with congatec Embedded BIOS features OEM Logo | OEM CMOS Defaults | LCD Control | Display Auto Detection | Backlight Control | Flash Update Power Management ACPI 5 .0 compliant | Smart Battery Management Operating Systems Microsoft® Windows 10 | Microsoft® Windows 10 IoT Enterprise | Microsoft® Windows IoT 10 Core | Linux | Android | Yocto | RTS Hypervisor Temperature Range Commercial: Industrial: Operating Temperature: 0 to +60°C Operating Temperature: -40 to +85°C Storage Temperature: -20 to +80°C Storage Temperature: -40 to +85°C Humidity Operating: 10 to 90% r. H. non cond. Storage: 50 to 95% r. H. non cond. Size 82 x 50 mm (approx. 3,23” x 1,97”)
Offering
Pico-ITX SBC based on Intel® Atom® x6000E, Intel® Pentium® and Celeron® J processor series High performance Intel® UHD Graphics (Gen11) Options for Industrial Temperature Range -40°C to 85°C Time Sensitive Networking and Time Coordinated Computing enable improved Realtime Capability Up to 4.267 MT/s Memory Support with Inband ECC UFS 2.0 for higher bandwidth and data processing
Offering
COM Express Compact Type 6 module based on Intel® Tiger Lake-UP3 high performing and low power Intel® Core™ processor series
