BCM Advanced Research (BCM) is a leading global supplier of industrial motherboards and embedded computing systems. Established in 1990, the company has transformed from a high-volume manufacturer for top personal computer brands to a recognized value leader in the computer motherboard industry. With a strong focus on reducing costs while maintaining product stability, BCM offers a wide range of standard industrial motherboards and systems, as well as flexible custom design services for its ODM/OEM customers. The company's products are widely used in various computer-based equipment and devices encountered daily, including self-serve kiosks, vending machines, POS systems, voting machines, fitness equipment, video conferencing systems, 3D printers, security surveillance, medical equipment, airport x-ray scanners, digital signage, slot machines, and automated lottery terminals. Through its innovative solutions and commitment to quality, BCM has established itself as a trusted partner for companies seeking reliable and cost-effective embedded computing solutions.
Offerings
Offering
The BC680R is built with Intel® R680E PCH and the LGA1700 CPU socket, which supports the 12th/13th/14th Gen Intel® Core™ I 9/7/5/3 processors delivering scalable high-performance for workstation-class computing applications. The BC680R supports 4 simultaneous independent displays, multiple high-end add-on cards, robust external USB connectivity, and 2.5GbE Ethernet communications. Select i9/i7/i5 processors with integrated Intel® Iris Xe/UHD Graphics (CPU Dependent). 4 x DIMM up to 128GB Max Dual Channel DDR5 5600MHz with ECC Support. 2 x Intel® I225-LM 2.5GbE Ethernet LAN ports. 1 x Gen 5 PCIe x16, 2 x Gen 4 PCIe x4, 1 x Gen 3 PCIe x4, 1 x Gen3 PCIe x1, 2 x Gen 3 PCIe x1 Open End. 2 x M.2 M-Key NVMe, 1 x M.2 E-Key supports CNVi. TPM 2.0, Intel® AMT 16. Supports 4 Independent Displays: 2 x HDMI, 2 x DP++. 6 x COM, 4 x SATA III8 x USB 3.2 Gen 2, 8 x USB 2.0, 1 x USB 3.2 Gen 2x2 Type-CI²C, SMBus, PS/2, LPT, 8-bit GPIO. Supports Win 10, Win 11, Linux
Offering
Budget-Friendly Mini ITX Motherboard Packs a Punch.An affordable Mini ITX with an Intel® Processor N97 onboard with integrated Graphics, offers a great balance of performance and value for compact, cost-effective system builds. Unlock uncompromising performance with our Intel® Alder Lake-N Quad-Core Mini ITX Motherboard. Featuring a low power 12W TDP Intel® Processor N97, integrated UHD Graphics, dual 2.5GbE LAN, USB 3.2 Gen2, USB-C, 6 COM, and extensive expansion options – all in a compact, single stack, value-packed design perfect for industrial, embedded, and edge computing applications.
Offering
NUC-RPLP is equipped with BCM ECM-RPLP 3.5inch SBC inside. Main features include small form factor embedded system with flexibility of adding additional external USB ports at rear I/O panel. Intel® Core™ i7/i5/i3 SoC Processor supports up to 12 Cores, code name Intel® Raptor Lake P Platform. 2 x DDR5 SODIMM sockets support up to 64GB system memory. Integrated Intel® Iris Xe Graphic/ Intel® UHD Graphics (CPU Dependent). 2 x DP++ support Dual Displays. Supports 3 Independent Displays. Integrated USB Type C Thunderbolt 4. Dual Intel® I226-LM Ethernet Controllers (2.5 GbE), 2 x LAN Ports. M.2 E-Key CNVi, M.2 M-Key NVMe, M.2 B-Key with Nano SIM Card Slot. 4 x USB 3.2 (rear side), 2 x USB 2.0 (front side). Flexible I/O Bay for 6 x USB 2.0 and 1 x COM Port. 12V-24V DC-In, and Fanless Operation.
Offering
MX-MTLPS is a Thin Mini ITX Motherboard engineered to power the most demanding edge AI applications. At its core lies the LGA 1851 socket, which supports the innovative Intel® Core™ Ultra Processor, combining an AI-ready CPU, GPU, and NPU to deliver stunning graphics and AI-focused performance, making it an ideal choice for edge computing solutions. The processor is built with integrated Intel® ARC™ Graphics, providing robust visual capabilities for a variety of applications. It also features the Intel® AI Boost Neural Processing Unit, which accelerates AI operations with high-performance parallel computing. For memory, the MX-MTLPS supports up to 64GB of 5600MHz DDR5, ensuring smooth and efficient multitasking capabilities. Connectivity is a breeze with its dual 2.5 GbE Ethernet LAN ports, offering high-speed network performance. Additionally, it supports four independent displays through 3 x DisplayPorts and an LVDS/eDP, perfect for multi-monitor setups. The motherboard’s design allows for fanless operation with a 15W CPU, ensuring silent performance in compact spaces. It also boasts a variety of USB ports, including dual USB Type-C Thunderbolt™ 4, which provides fast data transfer, power delivery, and video output. With additional features like Gen4 PCIe x4, 3 x M.2 slots, and 4 x COM ports, the MX-MTLPS is a versatile and powerful platform that stands ready to meet the needs of today’s edge AI applications.
Offering
MX-ADLPS Mini ITX motherboard adopts Intel’s breakthrough core technology – the first multichip package (MCP) Intel® Core™ processor platform in a socket, formerly Alder Lake PS platform. The socketed LGA multichip package (CPU+PCH) brings together the graphics and lower processor base power of Intel’s mobile processor with the benefits of Intel’s desktop processors. This architecture provides greater flexibility for compact design of a main board as well as scalable computing performance from the selections of Intel® Core SoC processors. Combining with additional cutting-edge technology enhancements including Thunderbolt 4, Iris Xe graphics, 4 DP++ 4K/8K displays, 2.5GbE LAN, the MX-ADLPS can be used for a wide range of deep learning, machine vision, and AI driven applications such as retail POS with object recognition, intelligent kiosk with object detection and analytic functions, medical imaging with AI assistance, digital surveillance, IoT video applications and more.
Offering
MX610H is a Mini-ITX motherboard built with LGA1700 CPU socket, Intel® H610E PCH with x4 Gen4 DMI and capable to support the 12th/13th/14th Gen Intel® Core® i9/i7/i5/i3, Pentium® , Celeron® processor family, code named the Alder Lake platform, up to 16 Cores 24 Threads Hybrid. Two SODIMM slots support DDR5 5200MHz system memory up to 64GB. MX610H provides 1 x Gen 4 SMT Type PCIe x16, 1 x M-Key M.2 2242/2280 NVMe (PCIe x4 + SATA III), 1 x E-Key M.2 2230 with CNVi Support (PCIe x 1 + USB 2.0) expansion interfaces. Built-in dual LAN Intel® I225-LM and Intel® I219-LM Ethernet Controllers provide 2.5GbE and 1 GbE network speed. The board supports TPM 2.0 and up to 3 independent displays via 1 x HDMI, 2 x DisplayPort and/or LVDS/eDP. The MX610H Mini-ITX also provides rich high-speed IO interfaces including 4 x USB 3.2 Gen 1x1 Ports, 2 x USB 2.0 Type A, 1 x USB 3.2 Gen 1x1 Header (2 Ports), 2 x USB 2.0 Headers (4 Ports), 4 x COM ports and 3 x SATA III. Windows 10, 11 and Linux supported.
Offering
MX-RPLPS Mini ITX motherboard is design based on Intel®'s multichip package (MCP) architecture with LGA1700 socket supporting Intel® Core™ processor, formerly Raptor Lake PS platform. This SoC in an LGA package allows for single-board design across the entire processor SKU stack, lowering R&D cost and accelerating time to market. Paring with the powerful Intel® Core™ edge processors, the MX-RPLPS Mini ITX motherboard delivers AI acceleration, graphics performance, and LGA flexibility for your edge deployments. MX-RPLPS provides two SODIMM sockets supporting DDR5 5200MHz up to 64GB system memory. Rich expansion interface includes Gen4 PCIe x4, M.2 E-Key, M-Key, B-Key with Nano SIM socket. External I/O includes 4 x DisplayPort, dual LAN, 4 x USB 3.2, 2 x USB 2.0, 1 x USB Type C Thunderbolt, and DC-in. Internal I/O include LVDS/eDP, dual SATAIII, 4 x COM ports, 2 x USB 3.2, 2 x USB 2.0, and GPIO. MX-RPLPS Mini ITX supports TPM 2.0, 12V-24V wide range DC input, and Win 10, 11 and Linux OS.
Offering
MX370QD industrial mini-ITX motherboard is equipped with LGA 1151 CPU socket with Intel Q370 express chipset supporting the 8th and 9th generation Intel® Core (2C/4C/6C/8C), Celeron® and Pentium® processors. When paired with an Intel® Q370 chipset, these processors offer even greater CPU and graphics performance as compared to previous generations. The board supports the native USB 3.1 Gen2 (10Gb/s) high-speed connectivity as well as the latest DDR4-2666 memory. The board also supports smooth 4K streaming on multiple displays enable simultaneous monitoring of ultra-high-definition video feeds. MX370QD supports Triple Display via 1 x HDMI, 2 x DP (DP++) and/or LVDS. The Mini ITX provides rich expansion interfaces including PCIe x16, M.2 Type M and Type A/E. TPM 2.0 is supported. MX370QD is ideally suited for applications like gaming, content creation, virtual reality, transactional retail terminals, digital security systems, and healthcare.
Offering
RX370Q is built with multiple High Reliability Gold Plating Connectors. Its socket LGA 1151 supports 8th/9th Generation Intel® Core™/Pentium®/ Celeron® Processors, formerly Coffee Lake/Coffee Lake Refresh platform. Paired with Intel® Q370 PCH. RX370Q provides 4 x Gold Plated DIMM slots support up to 64GB Dual Channel DDR4 2400MHz system memory with optional ECC Memory support. RX370Q supports 3 Independent Display via two DP/HDMI/LVDS. For Ethernet communication, RX370Q provides 2 x Gigabit LAN, Intel® I219-LM and Intel® I211-AT. Rich expansion interfaces include 6 x SATA III, 9 x USB 3.0, 6 x USB 2.0, 6 x COM. SATA RAID 0, 1, 5 and 10 is supported. Intel AMT 12, TPM 2.0 are also supported.
Offering
ECM-RPLP is one of our Intel® Edge Software-Qualified Hardware for AI and Edge Computing. It is a small yet powerful and fanless 3.5 inch Single Board Computer (SBC) built with the 13th Gen Intel® Core™ Processor Onboard, formerly Raptor Lake P Platform with many additional game-changing features. When coupling with select Intel® Core™ i7 and i5 processor, ECM-RPLP delivers integrated Intel® Iris Xe Graphic performance. The board provides two DisplayPorts 1.4a @60Hz with 4096x2160 resolution, and one 18/24 bits Dual Channel LVDS are provided at external I/O. eDP is optional. The board supports 3 independent displays. There is a Nano SIM Card Socket is provided on the back and at the edge of the board designed to support Cellular communication with easy Nano SIM Card access. ECM-RPLP provides integrated USB Type C Thunderbolt 4 connector delivering up to 40 Gbps data transfer speed. The board also provides 4 x USB 3.2 connectors at rear IO, and 2 x USB 2.0 onboard headers for 3 x USB 2.0 ports. There are two SODIMM sockets support two DDR5 4800MHz memory modules up to 32GB. M.2 E-Key supports CNVi module, M.2 M-Key supports NVMe module, and M.2 B-Key with Nano SIM card socket for cellular communication module.The ECM-RPLP is bottom layer soldered processor design. This design enables fanless operation by using a Passive Heatsink (15W CPU) with optional Fan (for 28W CPU) while maximizing the space for key features on the top side of the board.
Offering
OFT07W-ADLN is a 7 inch, ultra lightweight, slim and fanless All-in-One palm size open frame tablet powered by the onboard Intel® Processor N50 dual-core processor, formerly Alder Lake-N platform. The processor delivers 6M Cache, up to 3.40GHz turbo frequency at 6W TDP. The tiny tablet provides a 7" PCAP touch screen with resolution of 1024x600. 8GB DDR5 memory, 64GB eMMC onboard, Wi-Fi and Bluetooth module are all included. External I/O interfaces include one HDMI, two USB 3.0, one RJ45 LAN, 3-Ring Audio Jack and DC-in, which supports 12-24V wide range DC power. The tablet supports Windows 10, 11 and Linux Ubuntu 22.04.
Offering
NUC-ADLN is equipped with BCM ECM-ADLN-N97 3.5inch SBC inside. It is a small form factor Fanless embedded system equipped with onboard Intel® Processor N97, quad-core, 6M Cache, up to 3.60 GHz, up to 12W TDP, code name Intel® Alder Lake-N Platform, and 32GB eMMC. For memory, the board provides 1 x DDR5 SODIMM sockets support up to 16GB system memory. For graphics - integrated Intel® UHD Graphics. 2 x DP++ 1.4b 4K@60Hz support Dual Displays. For Ethernet, the board provides dual Intel® I226-LM Ethernet Controllers at 2.5 GbE, 2 x RJ45 LAN Ports. Expansion interface includes 1 x M.2 E-Key 2230, CNVi supports (PCIe x 1 + USB 2.0), and 1 x M.2 B-Key 2242/3042 with Nano SIM Card Socket (PCIe x1, SATAIII, & USB). Additional I/O includes 3 x USB 3.2 (Red) and 1 x USB Type C OTG at rear I/O, 2 x USB 2.0 at the front I/O, 1 x Combo Audio Jack, 1 x COM Port, lockable DC-in, and 2 x Knockout for SMA Connectors. The system is operated by12V-24V DC-In and it is Fanless Operation.
Offering
ECM-ADLN-N97 is a low power (12W TDP), fanless and thin 3.5" single board computer (SBC) designed based on the Intel® Processor N97 platform, formerly Alder Lake-N. The board is suitable for embedded computing applications that require a balance of performance, support of triple displays, power efficiency, quiet operation, thin and small size, and cost-effective.ThECM-ADLN-N97 features a quad-core Intel® Processor N97 onboard with a maximum turbo frequency of 3.6 GHz. It has 6 MB Intel® Smart Cache and integrated Intel® UHD Graphics (24EU GPU). For video output, the board supports three 4K60 SDR or one 4K60 HDR displays via 2 x DisplayPort 1.4b and LVDS or optional eDP interfaces. The ECM-ADLN-N97 is equipped with 32GB eMMC onboard. One SODIMM slot supports DDR5 4800 MT/s up to 16GB of system memory. The board is powered by 12V-24V wide range DC-in.The ECM-ADLN-N97 also provides many other connectivity features, including dual Intel® I226-V 2.5GbE Gigabit Ethernet, a USB Type-C OTG port, three USB 3.2 Gen2 Type-A. Two M.2 sockets support Wi-Fi, Bluetooth module, Nano SIM for communications as well as NVMe/SATA for storage and TPM 2.0 for security. ECM-ADLN-N97 supports Windows 10, 11 and Linux Ubuntu operation systems.
Offering
OFT10W-ADLN is a 10.1 inch, lightweight, slim and fanless All-in-One open frame tablet powered by the onboard Intel® Processor N50 dual-core processor, formerly Alder Lake-N platform. The processor delivers 6M Cache, up to 3.40GHz turbo frequency at 6W TDP. The tiny tablet provides a 10.1" PCAP touch screen with resolution of 1280x800. 8GB DDR5 memory, 64GB eMMC onboard, Wi-Fi and Bluetooth module are all included. External I/O interfaces include one HDMI, two USB 3.0, one RJ45 LAN, 3-Ring Audio Jack and DC-in, which supports 12-24V wide range DC power. The tablet supports Windows 10, 11 and Linux Ubuntu 22.04.
Offering
ECM-RPLP is a small yet powerful and fanless 3.5 inch Single Board Computer (SBC) built with the 13th Gen Intel® Core™ Processor Onboard with many additional game-changing features. When coupling with select Intel® Core™ i7 and i5 processor, ECM-RPLP delivers integrated Intel® Iris® Xe Graphic performance. Two DisplayPorts 1.4a @60Hz with 4096x2160 resolution, and one 18/24 bits Dual Channel LVDS are provided at external I/O. eDP is optional. The board supports 3 independent displays (2xDP + LVDS/eDP). USB Type C Thunderbolt™ 4. ECM-RPLP provides integrated USB Type C Thunderbolt™ 4 connector delivering up to 40 Gbps data transfer speed. The board also provides 4 x USB 3.2 connectors at rear IO, and 2 x USB 2.0 onboard headers for 3 x USB 2.0 ports. DDR5 SODIMM Sockets, 3 x M.2 Sockets Two SODIMM sockets support two DDR5 4800MHz memory modules up to 32GB. M.2 E-Key supports CNVi module, M.2 M-Key supports NVMe module, and M.2 B-Key with Nano SIM card socket for cellular communication module. Fanless Operation The ECM-RPLP is bottom layer soldered processor design. This design enables fanless operation by using a Passive Heatsink (15W) with optional Fan (28W) while maximizing the space for key features on the top side of the board allowing ease of installation of the DDR5 memory and M.2 modules. Additionally, two COM port headers support up to 4 COM ports, one SATA III connectors for storage. Two LAN ports powered by Intel® I226-LM Ethernet Controllers deliver 2.5GbE speed.
Offering
The BCM MX6412J is a fanless and Thin Mini-ITX motherboard designed on the low power embedded SoC Elkhart Lake platform. It features the latest 10nm architecture with the onboard Intel® Celeron® 6412J Quad Core processor with 1.5MB L2 Cache and up to 2.60 GHz CPU burst frequency with a low TDP of 10 watts. Its two DIMM slots support 3200MT/s DDR4 memory modules up to 32GB. MX6412J is a Mini-ITX motherboard with four LAN ports with two LAN supporting 2.5GbE speed. All of this I/O is on a low profile (single stack I/O) design. Also unique is the MX6412J supports up to three 4K/HD displays simultaneously. These two features are great solutions for network gateways and digital signage applications. The MX6412J is an ideal solution for applications that require a balance between cost and performance with practical features like the four LAN ports and support for three independent displays all within a 10W CPU TDP envelope. MX6412J is powered by 12-24V wide range DC-in.
Offering
RX610H Micro-ATX motherboard is built with LGA1700 CPU socket, Intel® H610E PCH with x4 Gen4 DMI and is capable to support the 12th/13th/14th Gen Intel® Core™ i9/i7/i5/i3, Pentium®, Celeron® processors, up to 16 Cores 24 Threads Hybrid. Select processors support Integrated Intel® Iris® Xe Graphic. 4 DIMM slots support DDR5 5600MHz system memory up to 64GB. The board provide rich expansion interfaces including 1 x Gen 5 PCIe x16, 1 x Gen 3 PCIe x1, 2 x Gen 3 PCIe x1, 1 x M.2 M-Key 2242/2280/22110 NVMe (PCIe x4 + SATA III), and 1 x M.2 E-Key 2230 with CNVi Support. For communication, the RX610H is equipped with Intel® I255-V and Intel® I219-V Ethernet controller support 2.5GbE and 1GbE via 2 LAN ports. RX610H supports 3 multi-displays via 1 HDMI and 2 DisplayPort. TPM 2.0 hardware security is supported. RX610H provides 2 x USB 2.0 Type A, 4 x USB 3.2 Type A, 2 x USB 2.0 Headers (4 Ports), 1 x USB 3.2 Gen 1 Header (2 Ports), 6 COM ports and 4 SATA III. Window 10, 11 and Linux OS are supported.
Offering
ECM-3455J is equipped with the 14nm Intel® Celeron® J3455 Quad Core 10 watts TDP low power SoC processor with integrated Intel® HD Graphics 500.The onboard 32GB eMMC is convenient and cost effective for most industrial applications. The J3455 quad-core CPU offers exceptional value-performance for applications in industrial, medical, healthcare, factory, and retail markets. For applications require larger capacity, the option of 64GB eMMC onboard is available for qualifying OEMs on a build to order basis.ECM-3455J is unique fanless design using the solid aluminum block heat-spreader to help transfer and release the heat with the reliability of not active fan. The low profile design of the ECM-3455J suits space saving applications that require fanless, and quiet operations.The board provides many cellular/WiFi/Bluetooth communication friendly I/O interfaces including M.2, mini-PCIe with SATA, uSIM support, I²C, SMBus, plus two Gigabit Ethernet LAN ports, and TPM 2.0 for hardware based security.While most of the small form factor motherboards with wide range DC power design supports from 12V to 24V, BCM ECM-3455J 3.5" SBC supports from 9V to 36V adding additional value and flexibility to suit wider range embedded applications:Industrial controlHuman Machine Interface (HMI)Digital SignageSmall Point-of-Sale Terminal, Retail KioskInteractive Self-serve KioskMedical and Healthcare equipment besides common OS support for Windows 10 IoT for x86 platform SBC, ECM-3455J also supports Linux and Android OS for mobile devices that require more computing power, more expansion and I/O interfaces with low power consumptions.
Offering
MX610HD is a value-Performance Optimized Thin-Mini ITX that supports 12th/13th/14th Gen Intel® Processor. The MX610HD is based on the new Intel® H610E PCH and the LGA1700 CPU socket which supports the 12th, 13th, 14th Gen Intel® Core™ 9/7/5/3 processor family, codenamed Alder Lake, Raptor Lake, and Raptor Lake Refresh, delivering unmatched scalable computing performance. The “H-Series” PCH offers exceptional value-performance in a low-profile Thin-ITX form factor ideal for installation behind an LCD display or embedding into a low-profile system. The MX610HD runs on 12V-24V wide range DC power and is equipped with many game-changing technologies including DDR5, Gen 4 PCI Express (PCIe), USB 3.2, and standardized 2.5GbE Ethernet. The MX610HD is an excellent solution for applications that require exceptional 12th/13th/14th Gen Intel® computing performance without some of the features offered in the “Q-Series” in order to achieve exceptional value-performance while maintaining in a thin profile design.
Offering
MX3350N thin mini-ITX motherboard is designed based on the newest 14nm Intel® Celeron® N3350 SoC platform (Formerly Apollo Lake). The two main features this new processor brings to BCM’s Intel Atom® product class are lower TDP and the capability of supporting three independent displays. The Intel® Celeron® N3350 processor is a dual-core 1.1 GHz SoC processor with a burst frequency capability of 2.4 GHz and a TDP of 6 watts which is lower than previous generation Intel® Celeron™ J1900 and Intel Atom® E3845 processors.MX3350 mini-ITX motherboard is an ideal solution for applications such as medical instrumentation, digital signage, HMI applications, kiosks, diagnostic equipment, industrial automation, and retail transaction equipment that require low power, fanless operation, and the ability to operate in a thin enclosure environments. It is also ideal for applications that require multiple display outputs such as digital systems with multiple user display input and output requirements. Intel® Celeron® N3350 Dual Core SoCSupports two DDR3L SoDIMM 1600 MHz systemmemory up to 8GBSupports Three Independent Displays1 x DP, 2 x HDMI2 x M.2 sockets, 1 x PCIe x14 x COM Ports6 x USB 3.0, 2 x USB 2.012V DC-inFanless OperationLow Profile Thin mini-ITXTPM 2.0Supported OS: Microsoft Windows 10 64-bit
Offering
OFT10W-3455J 10.1" Open Frame Tablet features PCAP touchscreen 1280x800 and is built with our ECM-3455J 3.5" SBC small form factor inside. The tablet is equipped with onboard Intel® Celeron® J3455 Quad Core SoC 2.3GHz Burst Frequency, codenamed Apollo Lake platform, with integrated Intel® HD Graphics 500 delivering outstanding computing performance with lower TDP. The OFT10W-3455J is equipped with 4GB RAM, 32GB eMMC, and Wi-Fi (802.11 a/c/b/g/n) & Bluetooth 5.0. for wireless communication. Multi-OS support includes Window 10, Linux and Android. The tablet provides rich external IO interfaces include dual RJ45 LAN ports, HDMI, 4 USB 3.0, Line-out, DC-in and optional RS-232/422/485 COM port. The tablet supports 9V to 36V wide range DC input.
Offering
The RX680R is a Micro ATX motherboard built with LGA1700 CPU socket, Intel® R680E PCH with x8 Gen4 DMI and is capable to support the 12th/13th/14th Gen Intel® Core™ i9/i7/i5/i3, Pentium®, Celeron® processor family up to 16 Cores 24 Threads Hybrid. Select processors support Integrated Intel® Iris® Xe Graphic. The board provides 4 x DIMM slots DDR5 5600MHz system memory up to 128GB with ECC support. Rich expansion slots include 1 x Gen 5 PCIe x16, 2 x Gen 4 PCIe x4, 1 x Gen 3 PCIe x4 Open Ended, 1 x M.2 M-Key 2242/2280/22110 NVMe (Gen 4 PCIe x4 + SATA III), 1 x M.2 M-Key 2242/2280/22110 NVMe (Gen 3 PCIe x4 + SATA III), and 1 x M.2 E-Key 2230 with CNVi Support (PCIe x 1 + USB 2.0). Two of the Intel® I225/226-LM Ethernet controllers onboard delivering 2.5GbE network speed. Infineon® TPM 2.0 is supported. The RX680R supports up to 4 independent displays via 4 DisplayPort. For USB interfaces, there are 6 x USB 3.2 Gen 2x1 Ports, 1 x USB 3.2 Gen 2x2 Type-C at the rear IO panel, and 1 x USB 3.2 Gen 2x1 Header (2 Ports), 4 x USB 2.0 Headers (8 Ports) and 1 x Thunderbolt Header onboard. The board also provides 6 COM ports, 4 SATA III and supports Windows 10, 11 and Linux OS.
Offering
The MX680RD is a Mini-ITX motherboard built with LGA1700 CPU socket, paired with Intel® R680E PCH with x8 Gen4 DMI, capable to support the 12th Gen Alder Lake/ 13th Gen Raptor Lake/ 14th Gen Raptor Lake Refresh up to 16 Cores 24 Threads Hybrid. The board provides two SODIMM sockets support Dual Channel DDR5 4800MHz up to 64GB with ECC support. Rich expansion interfaces include 1 x Gen 5 PCIe x16, 2 x M.2 M-Key 2242/2280 NVMe (PCIe x4 + SATA III), and 1 x M.2 E-Key 2230 with CNVi Support (PCIe x 1 + USB 2.0). There are two Intel® I225-LM Ethernet Controllers onboard delivering 2.5GbE network speed via two RJ45 LAN ports. TPM 2.0 is supported. The MX680RD provides four DisplayPorts 1.2a 4K@60Hz and onboard LVDS connector, support up to 4 independent display. For internal IO interfaces, the board provides 6 x USB 3.2 Gen 2x1 Type-A, 1 x USB 3.2 Gen 2x2 Type-C at the rear IO panel, and 1 x USB 3.2 Gen 2x1 (2 Ports), 2 x USB 2.0 Headers (4 Ports), 2 COM ports and 2 SATA III. The MX680RD supports 12V-24V Wide Range DC-In and Windows 10, 11 and Linux OS.
